SPECIFICATIONS

MSH3012RV-L

INVERTER SPECIFICATIONS

Input battery voltage operating range

9 to 17 VDC

Input battery voltage range for full output power

10.4 to 17.0 VDC

AC output voltage accuracy (at 12.6 VDC)

120 VAC ±3% (≤ continuous power)

Output frequency and accuracy

60 Hz ± 0.05 Hz

Total Harmonic Distortion (THD)

< 5%

Continuous power output (at 25°C)

3000 VA

Continuous AC output current (invert mode)

25 A

Continuous AC output current (charger mode)

50 A (pass-through and load support)

1 msec surge current (amps AC)

85

100 msec surge current (amps AC)

45

5 sec surge power (real watts)

3500

30 sec surge power (real watts)

3500

5 min surge power (real watts)

3400

30 min surge power (real watts)

3100

Maximum continuous input current

400 ADC

Inverter efficiency (peak)

88%

HBCO/HBCI (High Battery Cut Out/In)

17.1 VDC /16.5 VDC

LBCO/LBCI (Low Battery Cut Out/In)

13.0 VDC (adj with remote, firmware 1.9 or higher needed) / 12.5 VDC

Inverter stacking (series or parallel)

No

AC relay transfer time (minimum)

<16 msec

Power consumption – searching

10 watts

Power consumption – inverting (no load)

36 watts

Output waveform

Pure Sine Wave

CHARGER SPECIFICATIONS

Continuous output at 25° C

125 ADC

Input current for continuous rated output

18 AAC

Maximum current during load support

224 ADC from battery

Charger efficiency

86%

AC input frequency range

50 to 70 Hz

AC input voltage range

60 to 140 VAC (120 VAC nominal)

Power factor

> 0.95
