SRE11S Series

Slim metal rotary encoder, 11mm diameter, SMD or thru-hole

01

Features

Durable metal shaft & bushing

Slim 4.5mm body thickness

Low-noise design for 120RPM max.

Momentary switch available

Excellent detent feel

Custom options available

Applications

Panel control with continuous rotation. Popular for applications in

terms of audio, video, medical, industrial, or home appliance.

Encoder Specification

Switch Specification

How to order

SRE11S

Series

PPR

Mounting

VT Thru-hole

VS SMD

15 15 Pulse

Detent

1 No detent

2 With detent

Bushing, Shaft, Momentary Switch

Pulse Number of

detent

Phase difference

(msec)

Chattering

(msec)

Sliding noise

(msec)

Insulation

resistance

Dielectric

strength

Detent torque

(gf cm)

Rotational

life (cycle)

0

15

30

4

2

2

250V DC

100M MIN

300V AC

1 min

100±70

15,000

Rating

Contact

resistance

Insulation

resistance

Dielectric

strength

Contact

arrangement

Travel of

switch (mm)

Operating

force (gf)

Operating

life(cycle)

0.5

350±100

DC 5V

10 mA

100 m

250V DC

100M MIN

300V AC

1 min

PUSH ON

1.5

400±200

20,000

Please refer to page 2 & 3
