SPLR Series

Round pushbutton switch, 5 million cycles, optional LED

01

General Specifications

Circuit

Current Rating

Contact Resistance

Insulation Resistance

Operating Force

Total Travel

Operating Life

Operating Temperature

Solder Specifications

Materials

Cover

Cap

Reflector

Base

Lamp Term.

Act. Dome

End Term.

:SPST

:50mA @ 12VDC

:100mOhm Max.(initial)

:100MOhm Min.

:300gf 50gf

:0.3mm 0.1mm

:5,000,000 cycles Min.

:-25 deg.~+60 deg.

:260 deg. for 3 seconds

:Polycarbonate (PC)

:Polycarbonate (PC) or

Acrylonitrile Butadine Styrene(ABS)

:Polycarbonate (PC)

:Polyamide (PA)

:Phosphor bronze (PBS) with gold plating

:Phosphor bronze (PBS) with silver plating

:Brass with gold plating

EXAMPLE : SPLR-1-01-VA T

Illuminated tact switch -Red cap-Red led-Transparent VAT cover.

--

VAT Flat

Without Cover

CVT Concave

Cover style

SPLR

Function Code

LED

Indicator

L

-- Illuminated

Tactile Switches

Cap Colors

1

2

3

4

T

6

7

Red

Yellow

Green

White

Transparent

Orange

Blue

A

B

Ice

Snow

"*" not standard type

please inquire first

LED Colors

01

S2S

03

S3

P3S

4S

7S

17

1P3

P37

Red

Super Yellow

Green

Super Green

Pure Green(single)

White (single)

Blue (single)

Red/Blue*

Red/Pure Green*

Pure Green/Blue*

Standard switch unit

Switch with VAT cover

Switch with CVT cover

5.0

10.16

dia. 15.0

7.62

12.5

dia 15.0

dia 17.0

dia 17.0

HOW TO ORDER

DIMENSION
