TLV2465CPWR datasheet(21/58 Pages) TI

21 / 58 page

TLV2460, TLV2461, TLV2462, TLV2463, TLV2464, TLV2465, TLV246xA

FAMILY OF LOW POWER RAILTORAIL INPUT/OUTPUT

OPERATIONAL AMPLIFIERS WITH SHUTDOWN

SLOS220J − JULY 1998 − REVISED FEBRUARY 2004

WWW.TI.COM

TYPICAL CHARACTERISTICS

Figure 32

TOTAL HARMONIC DISTORTION

FREQUENCY

0.010

0.001

100

10k

f − Frequency − Hz

100k

0.1

VDD = ±1.5 V

VO(PP) = 2 V

RL = 10 kΩ

AV = 1

AV = 10

AV = 100

0.5

Figure 33

TOTAL HARMONIC DISTORTION

FREQUENCY

0.010

0.001

100

10k

f − Frequency − Hz

100k

0.1

VDD = ±2.5 V

VO(PP) = 4 V

RL = 10 kΩ

AV = 1

AV = 10

AV = 100

Figure 34

TOTAL HARMONIC DISTORTION PLUS NOISE

PEAK-TO-PEAK SIGNAL AMPLITUDE

0.010

0.001

0.1

VDD = 3 V

AV = 1

TA = 25

°C

RL = 10 kΩ

RL = 2 kΩ

RL = 250 Ω

RL = 100 kΩ

Peak-to-Peak Signal Amplitude − V

1.2 1.4

1.6

2.2 2.4

1.8

2.6 2.8

3.2

Figure 35

TOTAL HARMONIC DISTORTION PLUS NOISE

PEAK-TO-PEAK SIGNAL AMPLITUDE

0.010

0.001

0.1

VDD = 5 V

AV = 1

TA = 25°C

RL = 10 kΩ

RL = 250 Ω

RL = 100 kΩ

Peak-to-Peak Signal Amplitude − V

4.1

4.2

4.3

4.6

4.7

4.5

4.4

4.8

4.9

RL = 2 kΩ
