Mains Plug

Features:

• In compliance with EN 60309-1 and EN 60309-2 standards

• Enclosure, insert and locking in insulating, thermoplastic,

self-extinguishing material

• Cable anchoring collar incorporated in the insert

• Supplied with entry gland

• Entry with cable gland, RAL 7035 grey enclosure, locking

ring with gasket colour coded according to the operating

voltage

• Cable anchorage with retained screws

Specifications:

Series

: PEW16_sv

Gender

: Plug

Connector Mounting

: Cable

Contact Termination

: Screw

Connector Type

: Standard Power Entry

IP / NEMA Rating

: IP67

No. of Outlets

: 1

Current

Rating

(A)

Poles

A

B

PgØ

16

2P +

137

70

16

3P +

142

78

3P + N +

150

86

21

32

2P +

170

92

3P +

3P +N +

175

99.5

Important Notice : This data sheet and its contents (the “Information”) belong to the members of the Premier Farnell group of companies (the “Group”) or are licensed to it. No licence is granted

for the use of it other than for information purposes in connection with the products to which it relates. No licence of any intellectual property rights is granted. The Information is subject to change

without notice and replaces all data sheets previously supplied. The Information supplied is believed to be accurate but the Group assumes no responsibility for its accuracy or completeness, any

error in or omission from it or for any use made of it. Users of this data sheet should check for themselves the Information and the suitability of the products for their purpose and not make any

assumptions based on information included or omitted. Liability for loss or damage resulting from any reliance on the Information or use of it (including liability resulting from negligence or where the

Group was aware of the possibility of such loss or damage arising) is excluded. This will not operate to limit or restrict the Group’s liability for death or personal injury resulting from its negligence.

pro-POWER is the registered trademark of the Group. © Premier Farnell plc 2012.

Dimensions : Millimetres

Part Number Table

Description

Part Number

Plug, 240V, 2P+E, IP67

PEW1663SVB

Plug, 415V, 3 Pole, N+E, IP67

PEW1665SVB

Plug, 32A, 240V

PEW3263SVA
