CLM2D-RCC/ACC: PLCC4 RED & AMBER SMD LEDs

© 2021-2024 Cree LED. The information in this document is subject to change without notice. Cree®, the Cree logo and the Cree LED logo are registered

trademarks of Cree LED.

CLD-CT1374

REV 8

4

ORDER CODE TABLE

Color

Kit Number

Luminous Intensity (mcd)

Dominant Wavelength

Package

Min.

Max.

Color Bin

Min.(nm)

Color Bin

Max.(nm)

Red

CLM2D-RCC-CZ0C0BB3

4500

11200

RB

619

RB

624

Reel

CLM2D-RCC-CA0C0BB3

5600

11200

RB

619

RB

624

Reel

Amber

CLM2D-ACC-CZ0C0253

4500

11200

A2

584

A5

596

Reel

CLM2D-ACC-CA0C0253

5600

11200

A2

584

A5

596

Reel

CLM2D-ACC-CZ0C0343

4500

11200

A3

587

A4

593

Reel

CLM2D-ACC-CA0C0343

5600

11200

A3

587

A4

593

Reel

Notes:

•

The above kit numbers represent order codes that include multiple intensity-bin and color-bin codes. Only one intensity-bin code and one color-bin

code will be shipped on each bulk. Single intensity-bin code and single color-bin codes will not be orderable.

•

Please refer to the

HB LED Lamp Reliability Test Standards document for reliability test conditions.

•

Please refer to the

HB LED Lamp Soldering & Handling document for information about how to use this LED product safely.
