PLL502-02

Low Phase Noise VCXO (24MHz to 50MHz)

47745 Fremont Blvd., Fremont, California 94538 Tel (510) 492-0990 Fax (510) 492-0991 www.phaselink.com Rev 12/14/05 Page 2

PIN DESCRIPTIONS

Name

Number

Type

Description

XOUT

1

I

Crystal output. See Crystal Specifications on page 3.

N/C

2,7

-

Not connected.

VCON

3

I

Voltage Control input.

GND

4

P

Ground.

CLK

5

O

Output clock.

VDD

6

P

+3.3V power supply.

XIN

8

I

Crystal input. See Crystal Specifications on page 3.

ELECTRICAL SPECIFICATIONS

1. Absolute Maximum Ratings

PARAMETERS

SYMBOL

MIN.

MAX.

UNITS

Supply Voltage

4.6

V

Input Voltage, dc

-0.5

V

Output Voltage, dc

-0.5

V

Storage Temperature

-65

150

°C

Ambient Operating Temperature*

-40

85

°C

Junction Temperature

125

°C

Lead Temperature (soldering, 10s)

260

°C

ESD Protection, Human Body Model

2

kV

Exposure of the device under conditions beyond the limits specified by Maximum Ratings for extended periods may cause permanent damage to the

device and affect product reliability. These conditions represent a stress rating only, and functional operations of the device at these or any other

conditions above the operational limits noted in this specification is not implied.

* Note: Operating Temperature is guaranteed by design for all parts (COMMERCIAL and INDUSTRIAL), but tested for COMMERCIAL grade only.

2. DC Specifications

PARAMETERS

SYMBOL

CONDITIONS

MIN.

TYP.

MAX.

UNITS

Supply Current, Dynamic, with

Loaded Outputs

Output load of 10pF

16

20

mA

Operating Voltage

2.97

3.63

V

30

mA

Output drive current

(High Drive)

30

mA

10

mA

Output drive current

(Standard Drive)

10

mA

Short Circuit Current

±50

mA

VCXO Control Voltage

VCON

0

3.3

V
