PLL620-05/-06/-07/-08/-09

Low Phase Noise XO with multipliers (for 100-200MHz Fund or 3rdOT Xtal)

Universal Low Phase Noise IC’s

47745 Fremont Blvd., Fremont, California 94538 Tel (510) 492-0990 Fax (510) 492-0991 www.phaselink.com Rev 11/01/05 Page 1

FEATURES

Overtone Crystal.

• Output range: 100 – 200MHz (no multiplication),

200 – 400MHz (2x multiplier), 400 – 700MHz (4x

multiplier), or 800MHz-1GHz(PLL620-09 only, 8x

multiplier).

• CMOS (Standard drive PLL620-07 or Selectable

Drive PLL620-06), PECL (Enable low PLL620-08

or Enable high PLL620-05) or LVDS output

(PLL620-09).

• Supports 3.3V-Power Supply.

• Available in 16-Pin (TSSOP or 3x3mm QFN)

Note: PLL620-06 only available in 3x3mm.

Note: PLL620-07 only available in TSSOP.

DESCRIPTION

The PLL620-0x family of XO IC’s is specifically

designed to work with high frequency fundamental

and third overtone crystals. Their low jitter and low

phase noise performance make them well suited for

high frequency XO requirements. They achieve very

low current into the crystal resulting in better overall

stability.

BLOCK DIAGRAM

PIN CONFIGURATION

(Top View)

^: Internal pull-up

*: PLL620-06 pin 12 is output drive select (DRIVSEL)

(0 for High Drive CMOS, 1 for Standard Drive CMOS)

The pin remains ‘Do Not Connect (DNC)’ for PLL620-05/07/08/09.

OUTPUT ENABLE LOGICAL LEVELS

Part #

OE

State

0

(Default)

Output enabled

PLL620-08

1

Tri-state

0

Tri-state

PLL620-05

PLL620-06

PLL620-07

PLL620-09

1

(Default)

Output enabled

OE input: Logical states defined by PECL levels for PLL620-08

Logical states defined by CMOS levels for PLL620-05/-06/-

07/-09

X+

X-

OE

Q

Q

PLL by-pass

SEL

PLL

(Phase

Locked

Loop)

Oscillator

Amplifier

1

2

3

4

5

6

7

8

VDD

9

10

11

12

13

14

15

16

XIN

XOUT

SEL3^

SEL2^

OE

GND

GND

SEL0^

SEL1^

GND

CLKC

VDD

CLKT

GND

GND

PLL620-0x

GND

VDD

CLKT

CLKC

12

3

4

12

11

10

9

13

14

15

16

8

7

6

5

XOUT

XIN

SEL2^

OE
