CLM4B-RKB/AKB: PLCC4 1 IN 1 SMD LED

© 2021-2024 Cree LED. The information in this document is subject to change without notice. Cree®, the Cree logo and the Cree LED logo are registered

trademarks of Cree LED.

CLD-CT992

REV 7

2

ABSOLUTE MAXIMUM RATINGS (T

A = 25°C)

Items

Symbol

Absolute Maximum Rating

Unit

Forward Current

I

F

70

mA

Peak Forward Current Note1

I

FP

200

mA

Reverse Voltage

V

R

5

V

Power Dissipation

P

D

210

mW

Operation Temperature

T

opr

-40 ~ +100

°C

Storage Temperature

T

stg

-40 ~ +100

°C

Junction Temperature

T

J

110

°C

Junction/Ambient

R

THJA

300

°C/W

Junction/Solder Point

R

THJS

150

°C/W

Electrostatic Discharge

Classification (MIL-STD-883E)

ESD

Class 2

Note:

1.

Pulse width ≤0.1 msec, duty ≤1/10.

TYPICAL ELECTRICAL & OPTICAL CHARACTERISTICS (T

A = 25°C)

Characteristics

Color

Symbol

Condition

Unit

Minimum

Typical

Maximum

Forward Voltage

RKB/AKB

V

F

I

F = 50 mA

V

2.4

3.0

Reverse Current

RKB/AKB

I

R

V

R = 5 V

μA

10

Dominant Wavelength

RKB

λ

D

I

F = 50 mA

nm

618

624

630

AKB

λ

D

I

F = 50 mA

nm

584

591

599

Luminous Intensity

RKB

I

V

I

F = 50 mA

mcd

1120

1600

AKB

I

V

I

F = 50 mA

mcd

1120

1500

*

Continuous reverse voltage can cause LED damage.
