● PRC05 series are miniature size in comparison with PRC03, PRC04 series, also they are our original Push-Pull

Locking connectors for quick and easy maing.

● PRC07 series based on PRC05 series feature high density and miniaturization.

■ Specifications

■ Configuration

Plug

PRC05-P5F

Connections

Push-Pull Lock

Termination

Solder

Temperature and Humidity

-25º C to +85º C 85% Max.

NumberofPins

2,3,5,6,8,12

Shell Material / Finish

Brass / Nickel

Contact Material / Finish

Copper Alloy / Gold over Nickel

Insert

Size

No. of Pins

Dimensions (mm)

AB

C

D

E

F

G

H

J

K

L

M

N

6

2, 3, 5

13.5 32.0

5.2 13.0

2.0

9.5 18.0

9.0 P=0.5

9.0 11.5 16.0

2.2 32.5

9

6, 8

16.7 34.0

6.2 16.0

2.0

9.5 18.0 12.0 P=0.8

12.0 13.5 18.0

2.2 34.5

12

12

21.0 39.0 11.0 20.0

2.0

9.5 18.0 M16 P=1.0

16.0 17.0

22.5

2.8 39.0

Push-Pull Circular Connectors

PRC05 series / PRC07 series

TAJIMI ELECTRONICS CO., LTD.

F

G

E

B

N

4-øM

K

L

E

F

G

Flange Mount Receptacle

PRC05-RB5M

Bulkhead Mount Receptacle

PRC05-R5M

Jack

PRC05-J5M

25

25

25

25

25

* See page 28 as for Electrical Specifications.
