Cable

Conn

Cable Attachment

Dimensions, inches (millimeters)

Construction Notes

Military

Amphenol

Fig.

RG-/U

Type

Outer

Inner

a

b

c q

CAI

Plt.

Ins.

Other

Number

Number

8, 9, 11, 13,

Plug

Solder

Solder

1.50(38.0)

.750(19.0)

.444(11.3)

C1, C2

P4

D3

—

PL-259

83-1SP

1

63, 87A, 149,

Plug

Solder

Solder

1.50(38.0)

.750(19.0)

.444(11.3)

C1, C2 P1

D30

IBM 460147

PL-259

83-1SP-1050

1

213, 214,

Plug

Solder

Solder

1.50(38.0)

.750(19.0)

.420(10.7)

C1, C2 P1

D24

—

—

83-1SP-15RFX

1

216, 225

Plug

Solder

Solder

1.50(38.0)

.750(19.0)

.444(11.3)

C1, C2 P1

D1

TFE Insulation

PL-259

83-822

1

Plug

Crimp

Crimp

1.41(35.7)s .750(19.0)

.245(6.2)

C5

P2

D2

—

83-58DCP-2

2

58, 141

Plug

Solder

Crimp

1.38(35.1)

.716(18.2)

.212(5.4)

C5

P1

D24

83-58DCP-2RFX

2

Plug

FCP

Pliers

1.06(27.0)s .750(19.0)

.195(4.9)

C6

P2

D2

No Soldering

—

83-58FCP ❑

3

Plug

FCP

Pliers

1.16(29.4)s .716(18.2)

.224(5.7)

C6

P7

D24

No Soldering

—

83-58FCP-RFX

3

59, 62,140,210

Plug

Solder

Solder

1.68(42.9)

.781(19.8)

.257(6.6)

C2

P1

D30

—

UG-111/U

83-750

1

Reducing Adapter

1.00(25.4)

.438(11.1)

.209(5.3)

C2

P3

—

—

UG-175/U

83-185

4

For use on RG-55, 58,141,142 Cable (Except 55A)

1.00(25.4)

.437(11.1)

.209(5.3)

C2

P3

—

—

—

83-185-RFX

4

Reducing Adapter

1.00(25.4)

.438(11.1)

.257(6.5)

C2

P3

—

—

UG-176/U

83-168

4

For use on RG-59, 62, 71, 140, 210 Cable

1.00(25.4)

.437(11.1)

.257(6.5)

C2

P3

—

——

83-168-RFX

4

UHF CABLE PLUGS, REDUCING ADAPTERS

Fig. 1

UHF Solder Type Plugs

83-1SP

83-1SP-1050

83-1SP-15RFX

83-822

Fig. 2

UHF Crimp Type Plugs

83-58DCP-2

83-58DCP-2RFX

Fig. 3

UHF FCP Plugs

83-58FCP

83-58FCP-RFX

Fig. 4

UHF Reducing Adapters

83-185

83-185-RFX

83-168

83-168-RFX

v

v

v

v

v

v

v

v

v

v

v

c•

b

a

c•

b

a s

b

a s

a

b

c•

c•

UHF

Amphenol

®

Plugs, Reducing Adapters

187

Amphenol Corporation Tel: 800-627-7100

www.amphenolrf.com

• accommodates cable diameter

v distributor stocked s includes outer ferrule ❑ US patent 4,053,200
