HIGH CURRENT SHIELDED INDUCTOR

HIGH CURRENT SHIELDED INDUCTOR

HIGH CURRENT SHIELDED INDUCTOR

ASPI-4118-XXX

|||||||||||||||

10.4 x 10.4 x 4.5mm

LAND PATTERN

(Unit in mm)

PHYSICAL CHARACTERISTICS:

STANDARD SPECIFICATIONS:

FEATURES & APPLICATIONS:

TECHNICAL INFORMATION:

• Suface Mountable High Saturation Power Inductors

• Applications: Power supply for VTR, OA equipment, LCD television set, notebook PC,

portable communication, equipments, DC/DC converters, etc.

• Open Circuit Inductance

Test Parameters: 100KHZ, 0.25V

• DCR limits 25°C

• Tolerance of inductance:

ASPI-4118L- 0.36uH ±30%(N)

0.8uH~4.3uH ±20%((M)

ASPI-4118S- 0.22uH ±30%(N)

0.45uH~2.5uH ±20%((M)

• Saturation Rated Current: The current either the inductance value becomes

35% (tolerance: +30%) lower than its nominal value or becomes

25%(tolerance: +20%) lower than its nominal value. (Ta=25°C)

• Temperature Rise Current (Typ.): The actual current when temperature of

coil becomes

∆T=40°C (Ta=25°C)

PACKAGING INFORMATION:

ORDERING CODE:

• Parts are packaged on 13” reels. 500 parts per reel.

ASPI-4118L(S)- R80

Inductor

L (Low D.C.R Type)

S (Standard Type)

Size

L

(µH)

DCR

DCR

±20%

(m

Ω)(mΩ)

Max

Max

ASPI-4118S- R22

0.22

2.2

39.6

18.0

ASPI-4118L- R36

0.36

2.2

24.2

18.0

ASPI-4118S- R45

0.45

3.7

27.6

13.4

ASPI-4118L(S)- R80

0.80

3.7

16.2

13.4

5.9

20.7

10.2

ASPI-4118S- 1R3

1.3

11.8

16.6

7.3

ASPI-4118L- 1R4

1.4

5.9

12.2

10.2

ASPI-4118S- 1R8

1.8

18.6

13.3

5.4

ASPI-4118L- 2R2

2.2

11.8

9.8

7.3

ASPI-4118S- 2R5

2.5

21.8

11.8

5.0

ASPI-4118L- 3R2

3.2

18.6

8.1

5.4

ASPI-4118L- 4R3

4.3

21.8

7.0

5.0

ASPI-4118 (Standard Type)

Saturation

Rated

Current (A)

Temperature

Rise Current(A)

Saturation Rated

Current (A)

Temperature

Rise Current(A)

Part Number

ASPI-4118 (Low D.C.R Type)
