Ordering Information

Body Dimensions:

Length (A) x Width (B)

Model Series

Inductance Tolerance:

J = ±5%

K = ±10%

Inductance Code:

First 2 digits are significant.

Last digit denotes the number

of trailing zeros. For values

below 10µH, “R” denotes the

decimal point.

Optional Extended

Temperature Range:

-40°C to +125°C

BML1206-6R8K

.043/1.10

6.8

50

4

29

0.90

25

3K

BML1206-8R2K

.043/1.10

8.2

50

4

26

1.00

25

3K

BML1206-100K

.043/1.10

10.0

50

2

26

0.60

25

3K

BML1206-120K

.043/1.10

12.0

50

2

26

0.60

15

3K

BML1206-150K

.043/1.10

15.0

50

1

22

0.70

5

3K

BML1206-180K

.043/1.10

18.0

50

1

21

0.70

5

3K

BML1206-220K

.043/1.10

22.0

50

1

19

0.90

5

3K

BML1206-270K

.043/1.10

27.0

50

1

17

0.90

5

3K

BML1206-330K

.043/1.10

33.0

50

0.4

15

1.05

5

3K

1206 Specifications / Packaging

Dim. T

Test

DC

Rated

7”Reel

Part

Inch/mm

Inductance

Frequency

SRF

Resistance

Current

Qty

Number

Tol:

±.008/0.20

Q Min.

MHz

MHz Min.

IDC mA*

(Units)

*

Current Rating: The current at which a smaller change of inductance will occur due to either temperature increases or DC Current Superposition.

Outline Dimensions (Inches/mm)

Part #

A Dim.

B Dim.

C Dim.

BML 0603

.063±.006

.031±.006

.012±.008

(1608)

1.6±0.15

0.8±0.15

0.3±0.20

BML 0805

.079±.008

.049±.008

.02±.012

(2012)

2±0.20

1.25±0.20

0.5±0.30

BML 1206

.126±.008

.063±.008

.02±.012

(3216)

3.2±0.20

1.6±0.20

0.5±0.30

Refer to Specifications table for ‘T’ dimension of each model.

Lead-Free Option

LF = Lead - Free

(No code used for

non lead-free part)

BML 1206

1R0

K

ET

LF
