2007/08 EDITION MAGNETIC COMPONENTS SELECTOR GUIDE

We reserve the right to change specifications without prior notice

www.bitechnologies.com

127

• Meets the required 1500 Vrms line isolation

• Standard Operating Temperature Range

0°C to +70°C

• Extended Operating Temperature Range

-40°C to +85°C

• RoHS Peak Solder Rating 260°C

• Non-RoHS Peak Solder Rating 235°C



T3/DS3/E3/STS-1 Telecom Products

RoHS

Compliant

for

‘LF’ Models

Specifications

OCL

Packaging (mm)

Hi-Pot

Transformer

Primary : Secondary

(µH Min.)

Style

Pitch

Length

Width Height

(Vrms)

Notes:

(1) For Tape & Reel Packaging, add a “TR” suffix to the end of the Part Number when ordering, e.g. HT00-02107TR or HT00-02107LFTR (for RoHS Compliant)

(2) Add a “LF” suffix to the Part Number for RoHS compliant parts, e.g. HS00-02601LF or HS00-02601LFTR (for Tape & Reel)

(3) Contact BI Technologies for RoHS compliant part availability.

(4) CT is Center Tap & CS is Split Center Tap

HS00-00585

LF

Single

1:1

40

6-pin DIL

100 mil

12.70

8.90

6.35

3000

HS00-00588

LF

Single

1:2CT

19

6-pin SMT 100 mil

7.62

10.62

6.35

1500

HS00-00710

LF

Single

1:1

100

6-pin SMT 100 mil

7.62

9.91

6.35

1500

HT00-02107

LF

Single

1CT:1CT

40

6-pin SMT 100 mil

7.62

9.91

6.35

1500

HS00-02601

LF

Single

1:1

600

6-pin SMT 100 mil

7.62

9.91

6.35

1500

• Meets standard dielectric withstanding voltage requirements

• Standard Operating Temperature Range

0°C to +70°C

• Extended Operating Temperature Range

-40°C to +85°C

• RoHS Peak Solder Rating 260°C

• Non-RoHS Peak Solder Rating 235°C



Electrical / Environmental

VDSL Telecom Products

Specifications

Turns Ratio

Packaging (mm)

Hi-Pot

BI P/N

Chip: Line (±3%)

Style

Pitch

Length

Width

Height

(Vrms)

Notes:

(1) For Tape & Reel Packaging, add a “TR” suffix to the end of the Part Number when ordering, e.g. HT82-05099TR or HT82-05099LFTR

(for RoHS Compliant)

(2) Add a “LF” suffix to the Part Number for RoHS compliant parts, e.g. HT82-005087LF

(3) Tube Packaging only

LF

1:1CT

6-pin TH

2.54

12.7

8.89

6.35

3000

HT82-05099

LF

1:1CT

6-pin SMT

2.54

7.61

9.91

6.35

3000

RoHS

Compliant

for

‘LF’ Models
