FEATURES

-Low Proﬁle

-Full Selection of Turns Ratios

-Primary Rated for 10A

-Frequency Range up to 1MHz

-Suitable for Pick And Place Applications

-Withstands Solder Reﬂow

APPLICATIONS

-DC/DC Converters

-AC/DC Converters

SMT Current Sense Transformer

CT01 Series

Mechanical

Electrical Specifications

CT01-020-R

CT01-030-R

CT01-040-R

CT01-050-R

CT01-060-R

CT01-070-R

CT01-100-R

CT01-125-R

CT01-200-R

Part

Number

0.40

0.60

0.80

1.50

1.70

3.10

5.50

6.50

35.00

Rs

(Ω, max.)

500

Hi-Pot

1. Tested @ 10kHz, 0.1Vrms.

2. Electrical speciﬁcations at 25ºC.

3. Operating temperature range:

-40ºC to +130ºC.

4. Meets UL 94V-0.

5. Terminating resistor for 1 volt

out with 6 Amps AC ﬂowing

through the primary.

Ls

1

(µH, min.)

102

230

408

638

920

1250

1680

2620

6700

3.33

5.00

6.67

8.33

10.00

11.67

16.67

20.83

33.33

Terminating

5

Resistor (Ω)

Turns

Ratio

1:20

1:30

1:40

1:50

1:60

1:70

1:100

1:125

1:200

�

��

�

��

�

��

( 10/06) CT01-1

PACKAGING

-Reel Diameter: 13"

-Reel Width:

16mm

-Pieces Per Reel: 1000

Speciﬁcations subject to change without notice.

Recommend PCB Layout

Schematic

ICE Components, Inc.

Voice: 800.729.2099

Fax: 678.560.9304

cust.serv@icecomp.com

www.icecomponents.com
