AD820

Rev. H | Page 9 of 24

ABSOLUTE MAXIMUM RATINGS

Table 4.

Parameter

Rating

Supply Voltage

±18 V

Internal Power Dissipation

8-Lead PDIP (N)

1.6 W

8-Lead SOIC_N (R)

1.0 W

8-Lead MSOP (RM)

0.8 W

Input Voltage1

((V+) + 0.2 V) to

(V−) − 20 V

Output Short-Circuit Duration

Indefinite

Differential Input Voltage

±30 V

Storage Temperature Range

8-Lead PDIP (N)

−65°C to +125°C

8-Lead SOIC_N (R)

−65°C to +150°C

8-Lead MSOP (RM)

−65°C to +150°C

Operating Temperature Range

AD820A/AD820B

−40°C to +85°C

Lead Temperature(Soldering, 60 sec)

260°C

1 See Input Characteristics section.

THERMAL RESISTANCE

θJA is specified for the worst-case conditions, that is, a device

soldered in a circuit board for surface-mount packages.

Table 5. Thermal Resistance

Package Type

Unit

8-Lead PDIP (N)

°C/W

8-Lead SOIC_N (R)

160

°C/W

8-Lead MSOP (RM)

190

°C/W

Stresses above those listed under Absolute Maximum Ratings

may cause permanent damage to the device. This is a stress

rating only; functional operation of the device at these or any

other conditions above those indicated in the operational

section of this specification is not implied. Exposure to absolute

maximum rating conditions for extended periods may affect

device reliability.

ESD CAUTION
