ME12629B-R

BLUE

SIDE BACKLIGHT

FOR LCD DISPLAY

ABSOLUTE MAXIMUM RATINGS

Power Dissipation

Pd

8*120mW

Continuous Forward Current

IF

8*30mA

Reverse Voltage

VR

5V

Operating Temperature Range

Topr

-20 to +70°C

Storage Temperature Range

Tstg

-25 to +75°C

ELECTRO-OPTICAL CHARACTERISTICS (CHIP) (Ta=25°C)

PARAMETER

SYMBOL

MIN

TYP

MAX

UNIT

CONDITIONS

Forward Voltage

3.2

3.6

V

IF=20mA

Reverse Current

100

μA

VR=5V

Dominant Wavelength

λd

470

475

nm

IF=20mA

Spectral Line Half Width

Δλ

30

nm

IF=20mA

ELECTRO-OPTICAL CHARACTERISTICS (ME12629B-R) (Ta=25°C)

PARAMETER

SYMBOL

MIN

TYP

MAX

UNIT

CONDITIONS

Forward Current/Chip

16

mA

VS=5V DC,R=110Ω

Reverse Current/Chip

100

μA

VR=5V

Dominant Wavelength

λd

470

475

nm

VS=5V DC,R=110Ω

Spectral Line Half Width

Δλ

30

nm

VS=5V DC,R=110Ω

Brightness

B

180

200

cd/m

2

VS=5V DC,R=110Ω

CAUTION

Static eletricity and surge damages the backlight ,It is recommended to use a wrist band or anti-eletrostatic

glove when handling the backlight . All devices,equipment and machinery must be properly grounded.

REV : A

10/5/2006

P 1 OF 2

MICRO
