RoHS Directive 2002/95/EC Jan 27 2003 including Annex

Specifications are subject to change without notice.

Customers should verify actual device performance in their specific applications.

Max.

Hold

Trip

One Hour

Max. Time

Tripped

Interrupt

Current

Current

Initial Resistance

Post-Trip

To Trip

Power

Max.

Ratings

Resistance

@ 1 A

Dissipation

Model

Operating

Voltage

Volts

Amps

Amps

Amps

Ohms

Ohms

Ohms

Seconds

Watts

at 23

°C

at 23

°C

at 23

°C

at 23

°C

at 23

°C

at 23

°C

at 23

°C

Max.

Max.

Min.

Max.

Max.

Typ.

MF-R015/600

60

600

3

0.15

0.30

6.0

12.0

22.0

5.0

1.0

MF-R015/600-A

60

600

3

0.15

0.30

7.0

10.0

20.0

5.0

1.0

MF-R015/600-B

60

600

3

0.15

0.30

9.0

12.0

22.0

5.0

1.0

MF-R015/600-F

60

600

3

0.15

0.30

7.0

12.0

22.0

5.0

1.0

MF-R016/600

60

600

3

0.16

0.32

4.0

10.0

18.0

7.0

1.0

MF-R016/600-A

60

600

3

0.16

0.32

4.0

7.0

16.0

7.0

1.0

MF-R016/600-1

60

600

3

0.16

0.32

4.0

8.0

17.0

7.0

1.0

Electrical Characteristics

Features

■

Radial Leaded Devices

■

Maximum 600 VAC interrupt fault rating

■

Available in matched resistance “bins”

■

Ability to withstand lightning surges

■

RoHS compliant*, lead free

■

Agency recognition:

Applications

Customer Premise Equipment (CPE):

■

Modems

■

Cable modems

■

Fax machines

■

POS equipment

■

Security equipment

■

Set top boxes

Operating/Storage Temperature ..............................-40 °C to +85 °C

Maximum Device Surface Temperature

in Tripped State......................................................125 °C

Passive Aging ..........................................................+85 °C, 1000 hours ..........................................................±5 % typical resistance change

+60 °C, 1000 hours

±5 % typical resistance change

Humidity Aging ........................................................+85 °C, 85 % R.H. 500 hours ..........................................±5 % typical resistance change

Thermal Shock ........................................................MIL-STD-202F, Method 107G, ........................................±10 % typical resistance change

+125 °C to -55 °C,10 times

±15 % typical resistance change

Solvent Resistance ..................................................MIL-STD-202, Method 215B............................................No change

Lead Solerability ......................................................ANSI/J-STD-002

Flammability ............................................................IEC 695-2-2 ......................................................................No Flame for 60 secs.

Vibration ..................................................................MIL-STD-883C, Method 2007.1, Condition A..................No change

Environmental Characteristics

Test

Test Conditions

Accept/Reject Criteria

Visual/Mech. ......................................................Verify dimensions and materials..................Per MF physical description

Resistance ..........................................................In still air @ 23 °C ........................................Rmin ≤ R ≤ Rmax

Time to Trip ........................................................5 times Ihold, Vmax, 23 °C..........................T ≤ max. time to trip (seconds)

Hold Current ......................................................30 min. at Ihold............................................No trip

Trip Cycle Life ....................................................Vmax, Imax, 100 cycles ..............................No arcing or burning

Trip Endurance....................................................Vmax, 48 hours ..........................................No arcing or burning

UL File Number ..................................................E 174545S

CSA File Number ................................................CA 110338

Test Procedures And Requirements For Model MF-R/600 Series

Thermal Derating Chart - Ihold (Amps)

Ambient Operating Temperature

Model

-40

°C

-20

°C0 °C

23

°C

40

°C

50

°C

60

°C

70

°C

85

°C

MF-R015/600

0.233

0.206

0.178

0.150

0.124

0.110

0.096

0.083

0.062

MF-R016/600

0.249

0.219

0.190

0.160

0.132

0.117

0.103

0.088

0.066

Itrip is approximately two times Ihold.
