03/04/2006 V7.0

1

Features:

> High brightness surface mount LED.

> Designed for sideway illumination.

> 120° viewing angle.

> Small package outline.

> Qualified according to JEDEC moisture sensitivity Level 2.

> Compatible to both IR reflow soldering and TTW soldering.

Synonymous with function and performance, the DomiLED

perfectly suited for a variety of cross-industrial applications due to its

small package outline, durability and superior brightness.

DATA SHEET:

InGaN : DSx-xSx

© 2005 DomiLED is a trademark of DOMINANT Semiconductors.

All rights reserved. Product specifications are subject to change without notice.

Applications:

> Automotive: interior applications, eg: switches, telematics,

climate control system, dashboard, etc.

> Consumer Appliances: LCD illumination as in PDAs, LCD TV.

> Display: full color display video notice board.

> Industry: white goods (eg: Oven, microwave, etc.).

Semiconductors

Innovating Illumination
