04/04/2006 V9.0

1

Features:

> High brightness surface mount LED.

> 120° viewing angle.

> Small package outline (LxWxH) of 3.2 x 2.8 x 1.8mm.

> Qualified according to JEDEC moisture sensitivity Level 2.

> Compatible to both IR reflow soldering and TTW soldering.

> Environmental friendly; RoHS compliance.

With its significant power in terms brightness, viewing angle and variety of

application possibilities, Power DomiLED™ truly is a standout performer!

Ideal for automotive interior lighting as well as home, office and industrial

applications, it is also a proven performer in electronic signs and signals.

DATA SHEET:

InGaN : DWx

© 2005 DomiLED is a trademark of DOMINANT Semiconductors.

All rights reserved. Product specifications are subject to change without notice.

Applications:

> Automotive: interior applications, eg: switches, telematics,

climate control system, dashboard, etc.

exterior applications, eg: signal lighting,

Center High Mounted Stop Light (CHMSL),

> Display: full color display video notice board.

> Industry: white goods (eg: Oven, microwave, etc.).

> Lighting: architecture lighting, general lighting, garden light, etc
