ECM 1008 Ceramic / Ferrite Inductor

ECM Electronics Limited, Penmaen House, Ashington, West Sussex, RH20 3JR, UK

Tel: +44(0)1903 892810: Fax: +44(0)1903 892738. Email: ecm@ecmelectronics.co.uk

Although we have attempted to accurately reflect the products we market. ECM reserve the right without prior notice to

discontinue any product or make design changes we believe necessary.

Issue 3

ECM

Part

L

(nH)

Tol

%

Q Min.

SRF

Min.

(MHz)

MAX

(

Ω

Ω)

(mA)

EC1008A-010

10 @50MHz

J,K

50 @500MHz

4100

0.08

1000

EC1008A-012

12 @50MHz

J,K

50 @500MHz

3300

0.09

1000

EC1008A-015

15 @50MHz

J,K

50 @500MHz

2500

0.10

1000

EC1008A-018

18 @50MHz

J,K

50 @350MHz

2500

0.11

1000

EC1008A-022

22 @50MHz

J,K

55 @350MHz

2400

0.12

1000

EC1008A-027

27 @50MHz

G,J,K

55 @350MHz

1600

0.13

1000

EC1008A-033

33 @50MHz

G,J,K

60 @350MHz

1600

0.14

1000

EC1008A-039

39 @50MHz

G,J,K

60 @350MHz

1500

0.15

1000

EC1008A-047

47 @50MHz

G,J,K

65 @350MHz

1500

0.16

1000

EC1008A-056

56 @50MHz

G,J,K

65 @350MHz

1300

0.18

1000

EC1008A-068

68 @50MHz

G,J,K

65 @350MHz

1300

0.20

1000

EC1008A-082

82 @50MHz

G,J,K

60 @350MHz

1000

0.22

1000

EC1008A-R10

100 @25MHz

G,J,K

60 @350MHz

1000

0.56

650

EC1008A-R12

120 @25MHz

G,J,K

60 @350MHz

950

0.63

650

EC1008A-R15

150 @25MHz

G,J,K

50 @100MHz

850

0.70

580

EC1008A-R18

180 @25MHz

G,J,K

50 @100MHz

750

0.77

620

EC1008A-R22

220 @25MHz

G,J,K

50 @100MHz

700

0.84

500

EC1008A-R27

270 @25MHz

G,J,K

45 @100MHz

600

0.91

500

EC1008A-R33

330 @25MHz

G,J,K

45 @100MHz

570

1.05

450

EC1008A-R39

390 @25MHz

G,J,K

45 @100MHz

500

1.12

470

EC1008A-R47

470 @25MHz

G,J,K

45 @100MHz

450

1.19

470

EC1008A-R56

560 @25MHz

G,J,K

45 @100MHz

415

1.33

400

EC1008A-R68

680 @25MHz

G,J,K

45 @100MHz

375

1.47

400

EC1008A-R82

820 @25MHz

G,J,K

45 @100MHz

350

1.54

400

EC1008A-1R0

1000 @25MHz

G,J,K

35 @50MHz

290

1.75

370

EC1008A-1R2

1200 @7.9MHz

G,J,K

35 @50MHz

250

2.00

310

EC1008A-1R5

1500 @7.9MHz

G,J,K

25 @50MHz

200

2.30

330

EC1008A-1R8

1800 @7.9MHz

G,J,K

25 @50MHz

160

2.60

300

EC1008A-2R2

2200 @7.9MHz

G,J,K

25 @50MHz

160

2.80

280

EC1008A-2R7

2700 @7.9MHz

G,J,K

25 @25MHz

140

3.20

290

EC1008A-3R3

3300 @7.9MHz

G,J,K

25 @25MHz

110

3.40

290

EC1008A-3R9

3900 @7.9MHz

G,J,K

20 @25MHz

100

3.60

260

EC1008A-4R7

4700 @7.9MHz

G,J,K

20 @25MHz

90

4.00

260

EC1008A-5R6

5600 @7.9MHz

G,J,K

20 @7.9MHz

80

7.00

200

EC1008A-6R8

6800 @7.9MHz

G,J,K

20 @7.9MHz

60

8.00

180

EC1008A-8R2

8200 @7.9MHz

G,J,K

20 @7.9MHz

40

9.50

150

EC1008A-100

10000 @7.9MHz

G,J,K

20 @7.9MHz

25

12.0

100

TOLERANCES G=2%; J=5%; K=10%.
