ECM 1210 SMD Chip Inductor

ECM Electronics Limited, Penmaen House, Ashington, West Sussex, RH20 3JR, UK

Tel: +44(0)1903 892810: Fax: +44(0)1903 892738. Email: ecm@ecmelectronics.co.uk

Although we have attempted to accurately reflect the products we market. ECM reserve the right without prior notice to

discontinue any product or make design changes we believe necessary.

Issue 1

ECM

Part

L

(

µµH)

Tol

%

Q Min.

(**MHz)

SRF

Min.

(MHz)

MAX

(

Ω

Ω)

(mA)

ECM32T-100

10 @2.52MHz

J,K

30

36

2.1

150

ECM32T-120

12 @2.52MHz

J,K

30

33

2.5

140

ECM32T-150

15 @2.52MHz

J,K

30

30

2.8

130

ECM32T-180

18 @2.52MHz

J,K

30

27

3.3

120

ECM32T-220

22 @2.52MHz

J,K

30

25

3.7

110

ECM32T-270

27 @2.52MHz

J,K

30

20

5.0

80

ECM32T-330

33 @2.52MHz

J,K

30

17

5.6

70

ECM32T-390

39 @2.52MHz

J,K

30

16

6

65

ECM32T-470

47 @2.52MHz

J,K

30

15

7

60

ECM32T-560

56 @2.52MHz

J,K

30

13

8

55

ECM32T-680

68 @2.52MHz

J,K

30

12

9

50

ECM32T-820

82 @2.52MHz

J,K

30

11

10

45

ECM32T-101

100 @0.796MHz

J,K

20

10

10

40

ECM32T-121

120 @0.796MHz

J,K

20

10

11

70

ECM32T-151

150 @0.796MHz

J,K

20

8

15

65

ECM32T-181

180 @0.796MHz

J,K

20

7

17

60

ECM32T-221

220 @0.796MHz

J,K

20

7

21

50

TOLERANCES G=2%; J=5%; K=10%.

** = Test Frequency as specified in ‘L’ column
