ECM Axial Molded Choke

ECM Electronics Limited, Penmaen House, Ashington, West Sussex, RH20 3JR, UK

Tel: +44(0)1903 892810: Fax: +44(0)1903 892738. Email: ecm@ecmelectronics.co.uk

Although we have attempted to accurately reflect the products we market. ECM reserve the right without prior notice to

discontinue any product or make design changes we believe necessary.

Issue 1

ECM

Part

L

(

µµH)

Tol

%

Q Min.

(**MHz)

SRF

Min.

(MHz)

MAX

(

Ω

Ω)

(mA)

MF1501 Series continued…

MF1501T-5R6

5.6 @7.96 MHz

J

45

65

0.72

335

MF1501T-6R8

6.8 @7.96 MHz

J

50

55

1.02

280

MF1501T-8R2

8.2 @7.96 MHz

J

50

50

1.32

250

MF1501T-100

10 @7.96 MHz

J

50

46

1.62

220

MF1501T-120

12 @2.52 MHz

J

55

44

2.00

200

MF1501T-150

15 @2.52 MHz

J

45

49

0.80

315

MF1501T-180

18 @2.52 MHz

J

45

45

0.89

300

MF1501T-220

22 @2.52 MHz

J

45

41

0.96

290

MF1501T-270

27 @2.52 MHz

J

45

38

1.19

260

MF1501T-330

33 @2.52 MHz

J

45

34

1.37

240

MF1501T-390

39 @2.52 MHz

J

50

29

1.93

205

MF1501T-470

47 @2.52 MHz

J

50

27

2.11

195

MF1501T-560

56 @2.52 MHz

J

50

25

2.23

190

MF1501T-680

68 @2.52 MHz

J

50

21

2.70

170

MF1501T-820

82 @2.52 MHz

J

50

10.5

2.44

180

MF1501T-101

100 @2.52 MHz

J

50

10

3.12

160

MF1501T-121

120 @ 0.796 MHz

J

55

9.7

3.60

150

MF1501T-151

150 @ 0.796 MHz

J

55

8.5

4.10

140

MF1501T-181

180 @ 0.796 MHz

J

55

8

4.40

135

MF1501T-221

220 @ 0.796 MHz

J

55

7.5

5.00

125

MF1501T-271

270 @ 0.796 MHz

J

55

7

5.80

115

MF1501T-331

330 @ 0.796 MHz

J

55

6.5

6.40

110

MF1501T-391

390 @ 0.796 MHz

J

60

6.2

7.40

105

MF1501T-471

470 @ 0.796 MHz

J

60

5.7

9.50

92

MF1501T-561

560 @ 0.796 MHz

J

60

4.7

10.50

90

MF1501T-681

680 @ 0.796 MHz

J

60

4.5

11.8

80

MF1501T-821

820 @ 0.796 MHz

J

60

4.2

13.0

80

MF1501T-102

1000 @ 0.796 MHz

J

60

3.8

17.5

70

MF1501T-122

1200 @ 0.252 MHz

J

45

1.5

22.1

60

MF1501T-152

1500 @ 0.252 MHz

J

45

1.2

26.5

55

MF1501T-182

1800 @ 0.252 MHz

J

45

1.0

29.9

50

MF1501T-222

2200 @ 0.252 MHz

J

45

0.97

33.8

50

MF1501T-272

2700 @ 0.252 MHz

J

45

0.92

47.3

40

MF1501T-332

3300 @ 0.252 MHz

J

45

0.84

53.0

40

MF1501T-392

3900 @ 0.252 MHz

J

45

0.80

73.8

35

MF1501T-472

4700 @ 0.252 MHz

J

45

0.74

81.6

31

MF1501T-562

5600 @ 0.252 MHz

J

45

0.73

98.9

28

MF1501T-682

6800 @ 0.252 MHz

J

40

0.66

111

27

MF1501T-882

8200 @ 0.252 MHz

J

40

0.54

119

26

MF1501T-103

10000 @ 0.252 MHz

J

40

0.47

137

24

TOLERANCES J=5%; K= 10%; M=20%.

** = Test Frequency as specified in ‘L’ column
