CLX6F-RKB: PLCC6 3 IN 1 SMD LED

© 2021-2024 Cree LED. The information in this document is subject to change without notice. Cree®, the Cree logo and the Cree LED logo are registered

trademarks of Cree LED.

CLD-CT1379

REV 5

2

ABSOLUTE MAXIMUM RATINGS (T

A = 25°C)

Items

Symbol

Absolute Maximum Rating

Unit

Forward Current Note 1

I

F

3 x 50

mA

Peak Forward Current Note 2

I

FP

3 x 200

mA

Reverse Voltage

V

R

5

V

Power Dissipation

P

D

3 x 130

mW

Operation Temperature

T

opr

-40 ~ +85

°C

Storage Temperature

T

stg

-40 ~ +100

°C

Junction Temperature

T

J

110

°C

Junction/Ambient 1 chip on

R

THJA

450

°C/W

Junction/Solder Point 1 chip on

R

THJS

230

°C/W

Electrostatic Discharge

Classification (MIL-STD-883E)

ESD

1000V

Note:

1.

Single-color light

2.

Pulse width ≤0.1 msec, duty ≤1/10.

TYPICAL ELECTRICAL & OPTICAL CHARACTERISTICS (T

A = 25°C)

Characteristics

Condition

Symbol

Values

Unit

Dominant Wavelength

I

F = 3 x 20mA

λ

DOM

619~624

nm

Spectral bandwidth at 50% I

REL max

I

F = 3 x 20mA

Δ λ

24

nm

Forward Voltage

I

F = 3 x 20mA

V

F(avg)

2.1

V

V

F(max)

2.6

V

Luminous Intensity

I

F = 3 x 20mA

I

V(min)

2240

mcd

I

V(avg)

2800

mcd

Luminous Flux(Reference)

I

F = 3 x 20mA

Φ

V(avg)

8.4

lm

Reverse Current (max)

V

R = 5 V

I

R

10

μA

*

Continuous reverse voltage can cause LED damage.
