P4C1024L55CWC datasheet(5/11 Pages) PYRAMID

部件名	P4C1024L55CWC

功能描述	LOW POWER 128K x 8 CMOS STATIC RAM

PDF	11 Pages

Scroll/Zoom	100%

制造商	PYRAMID [Pyramid Semiconductor Corporation]

网页	http://www.pyramidsemiconductor.com

标志

5 / 11 page

P4C1024L

Page 5 of 10

Document # SRAM125 REV C

-55

Notes:

6. CE

1 and WE are LOW and CE2 is HIGH for WRITE cycle.

7. OE is LOW for this WRITE cycle to show twz and tow.

8. If CE

1 goes HIGH or CE2 goes LOW simultaneously with WE HIGH, the output remains in a high impedance state.

9. Write Cycle Time is measured from the last valid address to the first transitioning address.

AC CHARACTERISTICS - WRITE CYCLE

(Over Recommended Operating Temperature & Supply Voltage)

WRITE CYCLE NO. 1 (WE

WE CONTROLLED)(6)

Symbol

Parameter

Max

-70

Max

Unit

Min

Write Cycle Time

Chip Enable Time

to End of Write

Address Valid to

End of Write

Address Set-up

Time

Write Pulse Width

Address Hold

Time

Data Valid to End

of Write

Data Hold Time

Write Enable to

Output in High Z

Output Active from

End of Write
