1-Watt SMD 6mm

OVSPxBCR4 Series

Notes:

1.

Pulse width tp ≤ 10µs, Duty cycle = 0.1

2.

Thermal conductivity = 20K/W for red, yellow, green, blue; and 18K/W for white

Red, Yellow

Green, Blue

White

DC Forward Current

400mA

350mA

350mA

Peak Pulsed Forward Current

1

500mA

1000mA

1000mA

Reverse Voltage

12V

Not designed for reverse bias

Junction Temperature

2

125°C

120°C

125°C

Power Dissipation

Storage and Operating Temperature

-40°~ +100 °C

ESD Threshold (HBM)

2000V

1200mW

SYMBOL

PARAMETER

MIN

TYP

MAX

UNITS

Forward Voltage

2.2

2.5

2.8

V

Φ

Luminous Flux

Red

21

26

33

lm

Yellow

27

35

42

lm

Dominant Wavelength

Red

620

625

630

nm

Yellow

585

587

597

nm

Reverse Current

----

100

----

µA

2 Θ½

50% Power Angle

----

120

----

deg

SYMBOL

PARAMETER

MIN

TYP

MAX

UNITS

Forward Voltage

----

3.6

4.0

V

Φ

Luminous Flux

Blue

5.8

9

12

lm

Green

38

48

60

lm

Dominant Wavelength

Blue

464

470

476

nm

Green

525

530

535

nm

2 Θ½

50% Power Angle

----

120

----

deg

SYMBOL

PARAMETER

MIN

TYP

MAX

UNITS

Forward Voltage

----

3.6

4.0

V

Φ

Luminous Flux

39

48

63

lm

2 Θ½

50% Power Angle

----

120

----

deg

Reverse Current

----

10

----

µA
