SWC-112NF-R7 and SWC-112NM-R7

www.eravant.com | 424-757-0168 | support@eravant.com

Copyright © 2023 by Eravant

2/3

Final Rev 1.1

Mechanical Outline:

Unless otherwise specified, all dimensions are in inches [millimeters])

NOTE:

•

On condition that test data is provided it is collected from a sample lot. Actual data may vary slightly from unit to unit. All

testing is performed under +25 °C room temperature.

•

On condition that simulated test data is provided, actual measured data may slightly vary.

•

Eravant reserves the right to change the information presented without notice.

CAUTION:

•

Any foreign objects in the waveguide will cause performance degradation and may damage or destroy the unit.

•

Proper torque should be applied: 8.0 ± 0.15 inch-pounds (0.90 ± 0.02 Nm). Torque wrench model SCH-08008-S1 is highly

recommended
