SAP-10-R2

www.eravant.com | 424-757-0168 | support@eravant.com

Copyright © 2023 by Eravant

1/3

Rev 1.3

WR-10 Probe Antenna

SAP-10-R2 is a W-band probe antenna that operates from 75 GHz to

110 GHz. The antenna offers 6.5 dBi nominal gain and 115 degrees

typical half power beamwidth on the E-plane and 60 degrees typical half

power beamwidth on the H-plane. The antenna supports linear polarized

waveforms. The input of this antenna is a WR-10 waveguide with

UG387/U-M anti-cocking flange.

Electrical Specifications:

Mechanical Specifications:

Parameter

Minimum

Typical

Maximum

Frequency Range

75 GHz

110 GHz

Gain

6.5 dBi

Polarization

Linear

3 dB Beamwidth, E-Plane

115°

3 dB Beamwidth, H-Plane

60°

Side Lobes, E-Plane

-10 dB

Side Lobes, H-Plane

-14 dB

Return Loss

9 dB

Specification Temperature

+25°C

Operating Temperature

-40°C

+85°C

Item

Specification

Antenna Port

WR-10 Waveguide

Flange Type

UG-387/U-M Anti-Cocking Flange

Size

1.00” (L) x 0.75 (Ø)

Material

Brass

Finish

Gold Plated

Weight

0.4 Oz

Outline

AP-RW-A

ECCN

EAR99

FEATURES

•

Rectangular Waveguide Interface

•

Precisely Machined and Gold Plated

•

Linear Polarization

• High Return Loss

APPLICATIONS

•

Antenna Ranges

•

Antenna Gain Measurements

• System Setups

SUPPLEMENTAL DETAILS
