SAP-121F-R2

www.eravant.com | 424-757-0168 | support@eravant.com

Copyright © 2024 by Eravant

1/4

Final Rev 1.4

WR-12 Probe Antenna, 6.5 dBi Directivity with 1mm Coax Input

SAP-121F-R2 is an E-band probe antenna with a right angle (90°) 1 mm

(F) coax connector to cover the frequency range of 60 GHz to 90 GHz.

The antenna offers 6.5 dBi nominal directivity and 115 degrees typical

half power beamwidth on the E-plane and 60 degrees typical half power

beamwidth on the H-plane. The antenna supports linear polarized

waveforms.

Electrical Specifications:

Mechanical Specifications:

Parameter

Minimum

Typical

Maximum

Frequency Range

60 GHz

90 GHz

Directivity

6.5 dBi

Polarization

Linear

3 dB Beamwidth, E-Plane

115°

3 dB Beamwidth, H-Plane

60°

Side Lobes, E-Plane

-10 dB

Side Lobes, H-Plane

-14 dB

Return Loss

10 dB

Power Handling

10 W (CW)

Specification Temperature

+25°C

Operating Temperature

-40°C

+85°C

Item

Specification

Antenna Port (F)

1.0 mm (F) Coax Connector

Size

2.20

” (L) x 0.75 (Ø)

Material

Brass

Connector Material

Stainless Steel

Finish

Gold Plated

Weight

0.8 Oz

Outline

AP-REC-R

ECCN

EAR99

FEATURES

•

In the Configuration

•

Linear Polarization

APPLICATIONS

•

Antenna Ranges

•

Antenna Directivity Measurements

•

System Setups

SUPPLEMENTAL DETAILS
