Mechanical Outline:

Unless otherwise specified, all dimensions are in inches [millimeters])

NOTE:

•

All testing is performed under +25 °C room temperature.

•

This antenna is a mature product. The reasons for only providing simulated data can be found in the following blog

here.

•

Eravant reserves the right to change the information presented without notice.

CAUTION:

•

Any foreign objects in the waveguide will cause performance degradation and may damage or destroy the unit.
