ABRACON IS

ISO9001-2015

CERTIFIED

Ceramic Wirewound RF Inductor (AEC-Q200)

AISC-Q0402 Series

1.27 x 0.76 x 0.61 mm

RoHS/RoHS II Compliant

MSL Level = 1

Request Samples

Check Inventory

REVISION Initial Release :

11/21/2023

5101 Hidden Creek Ln, Spicewood TX 78669

Phone: 512-371-6159 Fax: 512-351-8858

For terms and conditions of sales, please visit:

www.abracon.com

Part

Number

Inductance

Code

L

(nH)

Tolerance

Q

L/Q Test

SRF

DCR

IDC

Min 900MHz

1.7GHz

Freq

Min

Max

(MHz)

(GHz)

(Ω)

(mA)

1N0

1.0

K

16

77

69

250

12.70

0.045

1360

1N9

1.9

C, D, J, K

16

68

82

250

11.30

0.070

1040

2N0

2.0

K

16

54

75

250

11.10

0.070

1040

2N2

2.2

J, K

19

59

100

250

10.80

0.070

960

2N4

2.4

K

15

51

68

250

10.50

0.070

790

2N7

2.7

J, K

16

42

61

250

10.40

0.120

640

3N3

3.3

K

19

65

87

250

7.00

0.066

840

3N6

3.6

J, K

19

45

71

250

6.80

0.066

840

3N9

3.9

J, K

19

50

75

250

5.80

0.066

840

4N3

4.3

J, K

18

47

71

250

6.00

0.091

700

4N7

4.7

J, K

18

48

68

250

4.70

0.130

640

5N1

5.1

G, J, K

20

56

82

250

4.80

0.083

800

5N6

5.6

J, K

20

54

81

250

4.80

0.083

760

6N2

6.2

J, K

20

52

76

250

4.80

0.083

760

6N8

6.8

G, J, K

20

63

78

250

4.80

0.083

680

7N5

7.5

G, J, K

22

60

88

250

4.80

0.104

680

8N2

8.2

J, K

22

57

84

250

4.40

0.104

680

8N7

8.7

J, K

18

54

73

250

4.10

0.200

480

9N0

9.0

J, K

22

62

78

250

4.16

0.104

680

9N5

9.5

J, K

18

54

69

250

4.00

0.200

480

10N

10

G, J, K

21

50

67

250

3.90

0.195

480

•

PPAP ready and supported

•

TS16949 certified production lines

•

AEC-Q200 (grade 1) qualified

•

Ceramic base with high SRF

•

Excellent DCR and current carrying characteristics.

•

Ultra-compact inductors

•

Tight tolerance down to ±2%

•

Automotive applications

•

Bluetooth, W-LAN, Broadband Network

•

Impedance matching networks

•

Filtering for high frequency communication

circuits

•

Video cameras, displays, and other electronic

devices.

Electrical Specifications

Applications

Features
