ABRACON IS

ISO9001-2015

CERTIFIED

Ceramic Wirewound RF Inductor (AEC-Q200)

AISC-Q0402 Series

1.27 x 0.76 x 0.61 mm

RoHS/RoHS II Compliant

MSL Level = 1

Request Samples

Check Inventory

REVISION Initial Release :

11/21/2023

5101 Hidden Creek Ln, Spicewood TX 78669

Phone: 512-371-6159 Fax: 512-351-8858

For terms and conditions of sales, please visit:

www.abracon.com

Test Conditions:

Inductance, Q, SRF: HP4286/E4982A

DCR: Micro-Ohm meter (Gom-801G)/E4982A

IDC: Applied the current to coils, the temperature of coil increases ΔT15℃(Ta=25℃).

Operating Temperature: -40°C to +125°C

Components Storage Temperature: -40°C to +125°C

Tape and Reel packaging Temperature: 15~28°C; < 80% RH

AISC-Q0402 is AEC-Q200 Qualified

AISC-Q0402 Series is RoHS Compliant and Pb free

Part

Number

Inductance

Code

L

(nH)

Tolerance

Q

L/Q Test

SRF

DCR

IDC

Min 900MHz

1.7GHz

Freq

Min

Max

Max

(MHz)

(GHz)

(Ω)

(mA)

11N

11

G, J, K

24

52

78

250

3.68

0.120

640

12N

12

G, J, K

24

53

71

250

3.60

0.120

640

13N

13

G, J, K

24

51

57

250

3.45

0.210

440

15N

15

G, J, K

24

55

77

250

3.28

0.172

560

16N

16

G, J, K

24

46

47

250

3.10

0.220

560

18N

18

G, J, K

25

57

62

250

3.10

0.230

420

19N

19

G, J, K

24

50

67

250

3.04

0.202

480

20N

20

G, J, K

25

52

53

250

3.00

0.250

420

22N

22

G, J, K

25

53

53

250

2.80

0.300

400

23N

23

G, J, K

24

49

64

250

2.72

0.300

400

24N

24

G, J, K

25

51

50

250

2.70

0.300

400

27N

27

G, J, K

24

49

63

250

2.48

0.300

400

30N

30

G, J, K

25

46

39

250

2.35

0.350

400

33N

33

G, J, K

24

31

32

250

2.35

0.350

400

36N

36

G, J, K

24

44

53

250

2.32

0.440

320

39N

39

G, J, K

25

47

45

250

2.10

0.550

200

40N

40

G, J, K

24

44

33

250

2.24

0.500

320

43N

43

G, J, K

25

46

34

250

2.03

0.810

100

47N

47

G, J, K

25

38

37

250

2.10

0.830

150

51N

51

G, J, K

25

47

37

250

1.75

0.820

100

56N

56

G, J, K

25

49

40

250

1.76

0.970

100

68N

68

G, J, K

22

45

38

250

1.62

1.120

100

82N

82

G, J, K

22

-

-

250

1.26

1.550

50

R10

100

G, J, K

22

-

-

250

1.16

2.000

30

R12

120

G, J, K

20

-

-

250

>1.80

2.660

50

Electrical Specifications (Cont’d)
