Ceramic Wirewound RF Inductor (AEC-Q200)

AISC-Q0603 Series

1.80 x 1.12 x 1.02 mm

RoHS/RoHS II Compliant

MSL Level = 1

Request Samples

Check Inventory

REVISION Initial Release :

11/21/2023

5101 Hidden Creek Ln, Spicewood TX 78669

Phone: 512-371-6159 Fax: 512-351-8858

For terms and conditions of sales, please visit:

www.abracon.com

Part

Number

Inductance

Code

L

(nH)

Tolerance

Q

L/Q Test

SRF

DCR

IDC

Min 900MHz

1.7GHz

Freq

Min

Max

(MHz)

(GHz)

(Ω)

(mA)

1N6

1.6

J, K

24

35

55

250

12.5

0.030

700

1N8

1.8

J, K

16

35

50

250

12.5

0.045

700

2N2

2.2

J, K

15

41

64

250

6.00

0.100

700

2N3

2.3

J, K

16

32

40

250

>4.00

0.140

700

3N3

3.3

G, J, K

22

47

65

250

>6.00

0.080

700

3N6

3.6

G, J, K

22

49

65

250

5.80

0.063

700

3N9

3.9

G, J, K

22

49

67

250

>6.00

0.080

700

4N3

4.3

G, J, K

22

49

67

250

5.80

0.063

700

4N5

4.5

G, J, K

20

55

92

250

5.80

0.120

700

4N7

4.7

G, J, K

25

53

67

250

5.80

0.120

700

5N1

5.1

G, J, K

20

47

56

250

5.80

0.160

700

5N6

5.6

G, J, K

20

56

77

250

5.80

0.170

700

6N2

6.2

G, J, K

25

60

85

250

5.80

0.110

700

6N3

6.3

G, J, K

25

41

61

250

5.80

0.110

700

6N8

6.8

G, J, K

27

60

81

250

5.80

0.110

700

7N5

7.5

G, J, K

28

60

65

250

4.80

0.106

700

8N2

8.2

G, J, K

27

64

81

250

4.80

0.110

700

8N7

8.7

G, J, K

28

62

58

250

4.80

0.109

700

9N1

9.1

G, J, K

35

70

80

250

4.80

0.130

700

9N5

9.5

G, J, K

28

59

61

250

5.40

0.135

700

10N

10

G, J, K

31

66

83

250

4.80

0.130

700

11N

11

G, J, K

31

53

56

250

4.00

0.086

700

12N

12

G, J, K

35

72

83

250

4.00

0.130

700

15N

15

G, J, K

35

64

89

250

4.00

0.170

700

16N

16

G, J, K

35

55

52

250

3.30

0.110

700

17N

17

G, J, K

35

56

44

250

3.20

0.170

700

•

PPAP ready and supported

•

TS16949 certified production lines

•

AEC-Q200 (grade 1) qualified

•

Ceramic base with high SRF

•

Excellent DCR and current carrying characteristics.

•

Ultra-compact inductors

•

Tight tolerance down to ±2%

•

Automotive applications

•

Bluetooth, W-LAN, Broadband Network

•

Impedance matching networks

•

Filtering for high frequency communication

circuits

•

Video cameras, displays, and other electronic

devices.

Electrical Specifications

Applications

Features
