Ceramic Wirewound RF Inductor (AEC-Q200)

AISC-Q0603 Series

1.80 x 1.12 x 1.02 mm

RoHS/RoHS II Compliant

MSL Level = 1

Request Samples

Check Inventory

REVISION Initial Release :

11/21/2023

5101 Hidden Creek Ln, Spicewood TX 78669

Phone: 512-371-6159 Fax: 512-351-8858

For terms and conditions of sales, please visit:

www.abracon.com

T: Tape & Reel: 4,000 pcs/reel

A

B

H

F

P

P0

P1

W

1.35

1.95

0.95

3.50

4.00

4.00

2.00

8.00

Dimensions: mm

ATTENTION: Abracon LLC’s products are COTS – Commercial-Off-The-Shelf products; suitable for Commercial, Industrial and, where designated, Automotive Applications. Abracon’s products

are not specifically designed for Military, Aviation, Aerospace, Life-dependent Medical applications or any application requiring high reliability where component failure could result in loss of life

and/or property. For applications requiring high reliability and/or presenting an extreme operating environment, written consent and authorization from Abracon LLC is required. Please contact

Abracon LLC for more information.

Packaging
