ASMT-Rx45-xxxxx

0.45mm Leadframe-Based Surface Mount ChipLED

Data Sheet

CAUTION: ASMT-Rx45 LEDs are Class 1C ESD sensitive per JESD22-A114C.01. Please observe appropriate

precautions during handling and processing. Refer to Application Note AN-1142 for additional details.

Description

Avago Technologies’ultra-thin ASMT-Rx45 ChipLEDs were

developed based on the industrial standard ChipLED

0603 platform which requires less board space. These

ChipLEDs provide a wide viewing angle of 130 degrees to

improve visibility in bright sunlight.

In addition to the high-brightness and compact size,

Avago’s ASMT-Rx45 ChipLEDs provide two significant

advantages in the production environment: They can

be easily soldered using IR solder reflow process, and

the package is qualified to a Joint Electronic Device En-

gineering Council (JEDEC) moisture sensitive level (MSL)

rating of 2a. For manufacturers, this rating means that

these ChipLEDs can be kept in the open air (30 degrees

C, 60 percent relative humidity) for up to four weeks after

being removed from its sealed package without the need

to remove absorbed moisture.

Avago’s ultra-thin Leadframe ChipLED available in Red,

Orange, Yellow Green and Amber colors, the ASMT-Rx45

series is ideal for use by lighting designers developing

backlighting for dashboards and entertainment consoles

in automobiles, backlighting of industrial switches and

buttons, and small pixel indoor signs.

Features

• Industrial 0603 platform – 1.6 x 0.8 x 0.45mm

• Automotive qualified

• Super wide 130 deg viewing angle

• JEDEC MSL 2a.

• Robust Operating Temperature from - 40 to +100 °C

• Junction Temperature Tj = 110 °C

• RoHS & IR Reflow compatible

Applications

1. Interior Automotive

• Navigation backlighting

• Audio panel backlighting

• Push Button backlighting

2. Office Automation, home appliances and industrial

equipment

• Front panel backlighting

• Push Button backlighting

• LCD backlighting

• Switches backlighting

• Navigation backlighting
