E5C4

E5C4

4

Dimensions

Note:

All units are in millimeters unless otherwise indicated.

93

+1

0

141

+1

0

189

+1

0

237

+1

0

285

+1

0

Terminal Arrangement

(Bottom View)

48 x 48

44.8 x 44.8

Dimensions with Flush-mounting Adapter (Accessory),

and Back Connecting Socket (Sold Separately)

Panel Cutout

Flush-mounting

adapter

Panel

Y92F-30 Flush-mounting adapter

P3G-08 Back

connecting socket

Tightening screw

(96) (see note)

Note:

109 mm for US08 Back Connecting Socket

60 min.

60 min.

Side-by-side Mounting

of N Controllers

N

2

3

456

L

Note:

1. Recommended panel thickness is 1 to 4 mm.

2. Close side-by-side mounting is possible (in a single direction).

Accessories (Order Separately)

P2CF-08 Front Connecting Socket

Terminal Arrangement/

Internal Connections

(Top View)

Mounting Holes

70 max.

Eight, M3.5 x 7.5 sems

Two,

4.5-dia.

holes

Two, 4.5 dia. or Two, M4

50 max.

20 max.

Note:

Can also be

mounted to a

DIN track.
