Important Notice

Performance figures, data and any illustrative material

provided in this data sheet are typical and must be

specifically confirmed in writing by Bookham before

they become applicable to any particular order or

contract. In accordance with the Bookham policy of

continuous improvement specifications may change

without notice. The publication of information in this

data sheet does not imply freedom from patent or other

protective rights of Bookham or others. Further details

are available from any Bookham sales representative.

Contact Information

BH12844 Rev 1.0 January 2007.

©Bookham 2006. Bookham is a registered trademark of Bookham Inc.

North America

Bookham Worldwide

Headquarters

2584 Junction Ave.

San Jose

CA 95134

USA

• Tel: +1 408 919 1500

• Fax: +1 408 919 6083

www.bookham.com

sales@bookham.com

Europe

Paignton Office

Brixham Road

Paignton

Devon

TQ4 7BE

United Kingdom

• Tel: +44 (0) 1803 66 2000

• Fax: +44 (0) 1803 66 2801

Asia

Shenzhen Office

2 Phoenix Road

Futian Free Trade Zone

Shenzhen 518038

China

• Tel: +86 755 33305888

• Fax: +86 755 33305805

+86 755 33305807

Ordering Information:

LU974C-R to LU974N-R

974nm Pump Laser Module,

Uncooled – Mini-DIL series

LU976C-R to LU976N-R

976nm Pump Laser Module,

Uncooled – Mini-DIL series

LU980C-R to LU980N-R

980nm Pump Laser Module,

Uncooled – Mini-DIL series

REFERENCE IEC 60825-1

Edition 1.2

INVISIBLE LASER RADIATION

AVOID EYE OR SKIN

EXPOSURE TO DIRECT OR

SCATTERED RADIATION

CLASS 4 LASER PRODUCT

Maximum Power >500mW

Wavelength >970nm

Power Levels

Product Code

Operating Power (EOL) (mW)

Kink free power (mW)

LU9xxC-R

100

120

LU9xxD-R

110

132

LU9xxE-R

120

144

LU9xxF-R

130

156

LU9xxG-R

140

168

LU9xxH-R

150

180

LU9xxJ-R

160

192

LU9xxK-R

170

204

LU9xxL-R

180

216

LU9xxM-R

190

228

LU9xxN-R

200

240

LASER RADIATION - AVOID EYE OR

SKIN EXPOSURE TO DIRECT OR

SCATTERED RADIATION

MAX POWER > 500mW

WAVELENGTH > 970nm

CLASS IV LASER PRODUCT

THIS PRODUCT COMPLIES WITH 21CFR 1040.10

Caution - use of controls or

adjustments or performance

of procedures other than those

specified herein may result in

hazardous radiation exposure.

RoHS Compliance

Bookham is fully committed to environment protection

and sustainable development and has set in place a

comprehensive program for removing polluting and

hazardous substances from all of its products. The

relevant evidence of RoHS compliance is held as part

of our controlled documentation for each of our

compliant products. RoHS compliance parts are

available to order, please refer to the ordering

information section for further details.

ISO14001:1996

EMS 504193

TL9000 Rev 3.0 (ISO9001:2000)

FM15040
