www.ti.com
P0
A
SCL
P3
Unstable
Data
Last Stable Bit
SDA
WRITE MODE (R/
= 0)
W
DUT
P-PORT LOAD CONFIGURATION
Pn
500
Ω
500
Ω
2
V
×
CC
0.7
V
×
CC
0.3
V
×
CC
C = 50 pF
(see Note A)
L
Slave
ACK
t
(see Note B)
pv
Pn
TCA6507
LOW-VOLTAGE 7-BIT I2C AND SMBus LED DRIVER
WITH INTENSITY CONTROL AND SHUTDOWN
SCPS164B – MAY 2007 – REVISED NOVEMBER 2007
PARAMETER MEASUREMENT INFORMATION (continued)
A.
CL includes probe and jig capacitance.
B.
All inputs are supplied by generators having the following characteristics: PRR
≤ 10 MHz, ZO = 50 Ω, tr/tf ≤ 30 ns.
C.
The outputs are measured one at a time, with one transition per measurement.
D.
All parameters and waveforms are not applicable to all devices.
Figure 15. P-Port Load Circuit and Voltage Waveforms
Copyright © 2007, Texas Instruments Incorporated
Submit Documentation Feedback
21
Product Folder Link(s): TCA6507
