www.dfi.com

Intel®

Q670E/

H610E

Chipset

Desktop

SMBus

DDI

DDI

HDA

eSPI

eSPI

S/PDIF

Front Audio

Audio Jack

(Line-out/Mic-in/Line-in (opt.))

2.5GLAN 2 / GLAN 2

GLAN 2

USB 3.2 Gen2 2x

SMBus & I2C

SPI BIOS

TPM 2.0

NPCT760AABYX

VGA

HDMI

Realtek

ALC888

Super IO

with WDT

Fan Control

H/W Monitor

Case Open

x8 DMI 4.0

GEN3

GEN3

GEN3

OR

OR

*BOM option INT USB 2.0 port 14 for H610E.

*BOM option INT USB 2.0 port 5/6 x2 for H610E.

Raptor

Lake-S

LGA 1700

Desktop

ECC-ram

2.5GLAN 1

USB 3.2 Gen2 2x

I226-V

MDI

SPI

NTS0104

EXT-OOB

Channel B

IT6516BFN

IC ReDriver

HDMI 2.0

PI3HDX1204

USB 2.0

USB 3.2 Gen2/Gen1

PCIe x1

USB 2.0 2x

PS/2 KB/MS

COM1(RS232/422/485)

w/Power DB9

COM3~6(RS232)

w/o Power HEADER

EXT-OOB

I2C connector

COM2(RS232/422/485)

w/o Power HEADER

4 IN 8 OUT

DIO HEADER

PCIe 4.0 x16

GEN5

PCIe x16 Slot

ASM1085

PCIe to PCI x2

MUX

PI3DBS16212

M.2 E Key

USB 3.2 Gen1 2x

USB 2.0 4x

USB 2.0 2x co-lay Type A

MUX

Select by BIOS

SATA 4x

(RAID 0,1,5,10)

USB 2.0 Type A

PCIe x1

PCIe x2

PCIe x1/CNVi

USB 3.2

USB 2.0

PCIe x4

SATA 3.0

USB 2.0

SATA 3.0

USB 2.0

USB 2.0

DDI

DP++

I226-LM co-lay

I219-LM

VPRO

I219-V

MDI

MDI

USB 2.0

USB 2.0

USB 3.2 Gen2/Gen1

PCIe x1

PCIe x1

MECHANICAL DRAWING

243.84

BLOCK DIAGRAM

M.2 M key (PCIe x2)

M.2 M key (PCIe x4)

M.2 M key (SATA)

PCIe x4

MUX SATA 3 (R7)

DDR5 5600 MHz

Support ECC/non-ECC

DDR5 5600 MHz

Support ECC/non-ECC

DDR5 5600 MHz

Support ECC/non-ECC

DDR5 5600 MHz

Support ECC/non-ECC

Channel A

80 port Header

H610E Only

Q670E Only
