CHARACTERISTIC

SPECIFICATION/DESCRIPTION

Cellular Carrier Certifications

AT&T, Verizon, Sprint, others pending

Technology/Bands

HSPA+/UMTS (800/850/900/1900/2100 MHz)

EDGE/GPRS/GSM (850/900/1800/1900 MHz)

EV-DO/CDMA (800/1900 MHz)

Data Rate (Downlink/Uplink)

HSPA+: 22 Mbps/6 Mbps, WCDMA: 384 kbps

GSM: 14.14kbps, GPRS: 85.6 kbps/42.8 kbps,

EDGE: 236.8 kbps/118.4 kbps

EV-DO: 3.1 Mbps/1.8 Mbps, CDMA 1xRTT: 153 kbps

Power Class

HSPA+/WCDMA: Class 3, GSM/GPRS 850/900 MHz: Class 4

GSM/GPRS 1800/1900 MHz: Class 1, EDGE: Class E2

Router Functionality

IPv4/IPv6, VPN (IPsec with IKE/ISAKMP, multiple tunnels,

DES/3DES/AES encryption, VPN pass-through, GRE forwarding), SSL/SSH,

SMS

Network Interface

RJ-45 Jack, 10/100 Base-T, 10/100 Mbps (auto-sensing), full-/half-duplex

(auto-sensing)

RF Antenna

2 dBi flexible omnidirectional antenna included, 11 dBi directional Yagi

optional

Power System

Power Over Ethernet, 18 VDC Injector included: 100-240 VAC 50/60Hz

primary source

Power Consumption

<6 W (CDMA Transmit), <2W idle. Built-in switching regulator

accomodates 12-48 VDC input.

Physical Package

Heavy die-cast Aluminum, black powder-coated finish, meets IP66

Standard for water and dust protection. Sealing gland for Ethernet cable

entry. Window in cover to view status LEDs.

Size

200 x 80 x 58 mm not including connectors; 0.570 Kg

Operating Environment

-40ºC to +70ºC

Warranty

1 Year Parts & Labor, XTRa-Care Extended Warranty 2 Year Extension avail-

able at nominal cost

This product allows you to connect an Ethernet network to the Internet via your choice of Cellular Service Providers

anywhere in the world. Qualcomm GobiTM 3000 technology supports essentially all of the RF bands, standards and pro-

tocols in use today. We do the work for you of provisioning your unit. We will contact you before shipment, open an

account with your chosen Cellular Service Provider and complete the configuration and testing of the link. The AvaLAN

AW-NetDrop provides all of the normal functions of an Ethernet router such as firewall, DHCP service, AES encryption,

tunneling and port routing.

The AvaLAN AW-NetDrop is packaged in a rugged and weatherproof diecast aluminum enclosure. Energy consumption

is low enough to accomodate solar power. The power connection to the AW-NetDrop is via POE (Power Over Ethernet),

allowing a single cable connection to the box. It may be equipped with a directional or omnidirectional antenna. The

standard omnidirectional antenna works well in most signal areas. An optional directional Yagi with 11 dBi of gain may

be used to improve reception in fringe locations.

The AW-NetDrop Gateway is at its best when mounted atop a tall pole with its antenna pointed toward

the appropriate cell tower and able to provide a robust and reliable Internet connection in a

remote fringe location. Connect your water tower, pumping station, power substation or

cabin in the woods and browse to it securely via the Internet and the cellular network.

AvaLAN’s products offer the ideal combination of price, range, data rate,

security, interference avoidance, quality-of-service, and a simple plug and

play set up with minimal user programming required.

4G Cellular Ethernet Gateway

www.avalanwireless.com

Corporate headquarters

:: (866) 533.6216

Technical support

:: (650) 384.0000

Screen Capture:

Web Browser-based

Configuration with built-in

help and tutorials

AW-NetDrop

Product Brief

Specifications

AW-NetDrop

4G Cellular Ethernet Gateway

Includes:

(1) 4G Cellular Ethernet Gateway

(1) AW-POE18i Power Over Ethernet

Injector with integrated power supply

Optional:

AW11-4G

Directional 11 dBi Yagi Antenna

To Order:
