PWE-102-R datasheet(4/24 Pages) AUTONICS

4 / 24 page

TOWER LIGHTS

PTMØ56mmLED3colorsin1Steady&FlashingwithBuzzer

LED Modules

LED Color

Part Number

Standard

Module

Dome Head

Module

3 colors

in 1

R/Y/G

PTM-02RYG

PTMD-02RYG

R/B/G

PTM-02RBG

PTMD-02RBG

Locking Bolts

Part Number

Size

B-PTE-1

M4, 65mm

3 colors in 1 LED modular components

Bright & even light distribution through prism-cut lenses

Fast & easy assembly with inter-locking construction

3 base body options

Optional 85dB Buzzer (fixed or adjustable volume)

NEMA 4x / IP65 rated

RoHS compliant

•

Buzzer Kits (Optional)

Buzzer Style

Part Number

Fixed Sound Level

MPZ-56F

Adjustable Sound Level

MPZ-56G

Order Information

Dimensions

Standard Modules

Dome Head Modules

Ø56

unit: mm

Buzzer Kits

Ø56

14.8

Sound Level Adjuster

See

Page 13-14

for Mounting Options and Accessories.

Buzzer Kit

Locking Bolt

Body Unit

LED

Module

Mounting

Accessories

PTE-A-□□

PTE-AF-□□

PTE-S-□□

PTE-SF-□□

PTE-TP-□□

PTE-TPF-□□

Lead Wire Connection

Terminal Connection

PTE-TC-□□

PTE-TCF-□□

Pole Mounting

Surface Mounting

Pole Mounting

Surface Mounting

Body Units

Body Type

Voltage

Part Number

Steady

Steady & Flashing

Lead Wire

Connection

Pole

Mounting

AC 90~240V

PTE-A-FF

PTE-AF-FF

DC/AC 24V

PTE-A-02

PTE-AF-02

Surface

Mounting

AC 90~240V

PTE-S-FF

PTE-SF-FF

DC/AC 24V

PTE-S-02

PTE-SF-02

Terminal

Connection

Pole

Mounting

AC 90~240V

PTE-TP-FF

PTE-TPF-FF

DC/AC 24V

PTE-TP-02

PTE-TPF-02

Surface

Mounting

AC 90~240V

PTE-TC-FF

PTE-TCF-FF

DC/AC 24V

PTE-TC-02

PTE-TCF-02
