FIBER OPTIONS

Type

Spot diameter

(mm in) (Note)

Distance to

focal point

(mm in) (Note)

Lens

Fiber

Shape

(mm in)

Model No.

Shape

Emitting fiber

core (mm in)

Model No.

Finest spot

lens

ø0.1 ø0.004

approx.

7 ±0.5

0.276 ±0.020

FX-MR7

ø0.125 ø0.005

FD-R33EG

ø0.125 ø0.005

FD-EG31

ø0.15 ø0.006

approx.

ø0.175 ø0.007

FD-R34EG

ø0.2 ø0.008

approx.

ø0.25 ø0.010

FD-R32EG

ø0.25 ø0.010

FD-EG30

ø0.4 ø0.016

approx.

ø0.5 ø0.020

FD-R31G

ø0.5 ø0.020

FD-32G

ø0.5 ø0.020

FD-32GX

ø0.5 ø0.020

FD-42G

ø0.5 ø0.020

FD-42GW

Type

Spot diameter

(mm in) (Note)

Sensing range

(mm in)

(Note)

Lens

Applicable fibers

Shape

(mm in)

Model No. Emitting fiber

core (mm in)

Model No.

ø0.4 to ø2.0 ø0.016 to ø0.079 approx.

10 to 30

0.394 to1.181

FX-MR8

ø0.125 ø0.005 FD-R33EG, FD-EG31

ø0.4 to ø2.2 ø0.016 to ø0.087 approx.

ø0.175 ø0.007

FD-R34EG

ø0.5 to ø2.5 ø0.020 to ø0.098 approx.

ø0.25 ø0.010

FD-R32EG, FD-EG30

ø0.8 to ø3.5 ø0.031 to ø0.138 approx.

ø0.5 ø0.020

FD-R31G, FD-32G, FD-32GX, FD-42G, FD-42GW

ø4.0 ø0.157 approx.

0 to 30

0 to 1.181

FX-MR9

ø0.125 ø0.005

FD-R33EG, FD-EG31

ø0.175 ø0.007

FD-R34EG

ø0.25 ø0.010

FD-R32EG, FD-EG30

ø0.5 ø0.020

FD-R31G, FD-32G, FD-32GX, FD-42G, FD-42GW

15.3

0.602

ø5 ø0.197

15

0.591

ø5 ø0.197

ø5 ø0.197

10

0.394

Others

Designation

Model No.

Description

Protective tube

(For thru-beam

type fiber)

FTP-500 (0.5m 1.641 ft)

For

M4

thread

FT-42

FT-42S

FT-42W

FT-43

FT-H13-FM2

The protec-

tive tube,

made of

noncorro-

sive stain-

less steel,

protects

the inner

fiber cable

from any

external

forces.

FTP-1000 (1m 3.281 ft)

FTP-1500 (1.5m 4.922 ft)

FTP-N500 (0.5m 1.641 ft) For

M3

thread

FT-31

FT-31S

FT-31W

FD-31

FD-31W

FTP-N1000 (1m 3.281 ft)

FTP-N1500 (1.5m 4.922 ft)

Protective tube

(For reflective

type fiber)

FDP-500 (0.5m 1.641 ft)

For

M6

thread

FD-61

FD-61G

FD-61S

FD-61W

FD-62

FD-H13-FM2

FDP-1000 (1m 3.281 ft)

FDP-1500 (1.5m 4.922 ft)

FDP-N500 (0.5m 1.641 ft) For

M4

thread

FD-41

FD-41W

FD-41S

FD-41SW

FDP-N1000 (1m 3.281 ft)

FDP-N1500 (1.5m 4.922 ft)

Fiber bender

FB-1

The fiber bender bends the sleeve part of the

fiber head at the proper radius. (Note 1)

Universal sensor

mounting stand (Note 2)

MS-AJ1-F

Horizontal mounting type Mounting stand assembly for fiber

(For M3,M4 or M6 threaded head fiber)

MS-AJ2-F

Vertical mounting type

Single-core

holder

FX-AT15A

The incident light intensity may vary when using a multi-core fiber or a thin type sharp

bending fiber. This holder suppresses the variation in the incident light intensity. Brown.

Notes: 1) Do not bend the sleeve part of any side-view type fiber or ultra-small diameter head type fiber.

2) Refer to the universal sensor mounting stand

MS-AJ series pages for details.

•

FTP-□

•

FDP-□

•

FB-1

•

MS-AJ1-F

•

MS-AJ2-F

•

FX-AT15A

Single-core

holder

Fiber bender

Protective tube

Universal sensor mounting stand

Using the arm which enables adjustment in the horizontal direction,

sensing can also be done from above an assembly line.

360°

Angle adjustment: ±20°

20°

20°

Height adjustment:

150 mm 5.906 in approx.

Mounting hole for M6 screw

Forward / back adjustment:

130 mm 5.118 in approx.

Swivel: 360° rotation

360°

Angle adjustment: ±20°

20°

20°

Height adjustment:

150 mm 5.906 in approx.

Mounting hole for M6 screw

Forward / back adjustment:

130 mm 5.118 in approx.

Swivel: 360° rotation

Refer to p.69~ for details of lens dimensions.

Lens (For square head M3 reflective fiber)

Note: Spot diameter, distance to focal point and sensing range are specified for a red LED type amplifier.
