Industrial Systems

IPC920

Fanless Industrial System with LGA1700 Socket 14th/13th/12th Gen Intel® Core™ i9/i7/i5/i3 or

Celeron® Processor, Intel® H610E/R680E, and Front-access I/O

Specifications

Standard Color

Silver & black

Construction

Aluminum extrusion heavy-duty cold-rolled steel

Processor System

CPU Level

14th/13th/12th gen Intel® Core™ processor, up to 65W*

Chipset

Intel® H610E/R680E

System Memory

2 x 262-pin DDR5 4800 ECC/non-ECC SO-DIMM, up to 96GB**

System I/O

Ethernet

2 x RJ-45 2.5GbE LAN (Intel® I226-V)

1 x RJ-45 GbE LAN (Intel® I219-LM); with Intel® AMT (R680E)

Serial

2 x RS-232 (4-wire)/422/485 (default RS-232), DB9 (by BIOS selection)

USB

Intel® H610E:

2 x USB 3.2 Gen2 (10G) Type-A

2 x USB 3.2 Gen1 (5G) Type-A

1 x USB 2.0 180D Type-A (internal, up to 30 mm)

Intel® R680E:

4 x USB 3.2 Gen2 (10G) Type-A

1 x USB 2.0 180D Type-A (internal, up to 30 mm)

Display

1 x DisplayPort++ 1.2 with support for 4096 x 2160 resolution

1 x HDMI 1.4b with support for 4096 x 2160 resolution

TPM

TPM 2.0

NEW

1. 1 x HDD/SSD access LED & 3 x user's LED

2. Power on/off button with LED

3. 2 x 2.5GbE LAN (Intel® I226-V)

4. 1 x GbE LAN (Intel® I219-LM)

5. 1 x HDMI, 1 x DisplayPort++

6. 4 x USB 3.2

7. 3-pin terminal block for DC input

8. 2 x HDD/SSD tray

9. 1 x Remote power switch

10. Flexible I/O window

8

Features

● Intelligent power management: Ignition and USB power on/off control

● Supports Intel® RAID (R680E)

● Easy expansion via flexible I/O window

● Supports connectors with pull-resistance design

● Optional DIN-rail, bookshelf and wall mount kit

● EN 61000-6-2 certified

11. 2 x RS-232/422/485

12. 1 x PCIe x16 slot

13. 3 x Antenna opening

2

3

4

5

6

7

9

1

10

11

13

12

Wide Temp.

DDR5

Dual-View

Fanless

IP40
