Part Number: 47 Series

High Current - 1 Form A / 2 Form A - PhotoDMOS Relays

Product Data Sheet

Relays

ITEM

SYMBOL

VALUE

OUTLINE PACKAGE

SOP 4/8

DIP 4/8

SMD 4/8

DIP 6

SMD 6

1CH

2CH

1CH

2CH

1CH

Input

Continuos LED Current

IF

50 mA

Peak LED Current (f=100 Hz, duty=1%)

IFP

500 mA

LED Reverse Voltage

VR

5 V

Input Power Dissipation

PIn

75 mW

Output

Load Voltage

VL

80 V (AC peak or DC)

Load Current (A)

IL

1.25

1.0

1.25

1.0

2.0

Peak Load Current (1 ms, 1 shot) (A)

IPeak

3.0

3.5

3.0

3.0

5.0

Output Power Dissipation (mW)

POut

350

450

350

450

500

Total Power Dissipation (mW)

PT

400

500

400

500

550

I/O Breakdown Voltage (Vrms)

VI/O

1500

1500

3750

3750

3750

Operating Temperature

TOpr

-40˚ +85˚C

Storage Temperature

TStg

-40˚ +100˚C

ITEM

SYMBOL

MIN

TYP

MAX

UNITS

CONDITIONS

Input

LED Forward Voltage

VF

1.0

1.37

1.5

V

IF = 10mA

Operation LED Current

IF On

1.2

3.0

mA

Recovery LED Voltage

VF Off

0.5

1.0

V

Output

On-Resistance Drain to Drain

ROn

0.15

0.1(DIP6)

0.5

0.16(DIP6)

Ω

IF = 5mA

IL = Rating Time to flow is

within 1 sec.

Off-State Leakage Current

ILeak

1.0

μA

VL=80V

Output Capacitance

COut

190

500(DIP6)

pF

VL=0V, f=1MHz

Transmission

Turn-On Time

TOn

0.7

3.0

ms

IF = 5mA

IL = Rating

(for SOP/DIP4 - 8 type)

Turn-Off Time

TOff

0.06

0.5

ms

Turn-On Time

TOn

0.7

3.0

ms

IF = 10mA

IL = Rating

(for DIP6 type)

Turn-Off Time

TOff

0.04

0.5

ms

Coupled

I/O Insulation Resistance

RI/O

109

Ω

I/O Capacitance

CI/O

1.3

pF

f = 1MHz

ABSOLUTE MAXIMUM RATINGS (Ambient Temperature: 25˚C)

ELECTRICAL SPECIFICATIONS (Ambient Temperature: 25˚C)

Rev: 0 - Date: June/17/2016 - Signature: BR

80 VOLTS

High Current

up to 2A
