PM-65

ORDER GUIDE

Type

Appearance (mm in)

Sensing range

Model No.

Output

Output operation

26

1.024

22.4

0.882

7 0.276

6 mm 0.236 in (fixed)

PM-K65

NPN open-collector

transistor

Incorporated with 2 outputs:

Light-ON / Dark-ON

PM-K65-P

PNP open-collector

transistor

22.4

0.882

26

1.024

13.7 0.539

PM-T65

NPN open-collector

transistor

PM-T65-P

PNP open-collector

transistor

16.7 0.657

22.4

0.882

26

1.024

PM-T65W

NPN open-collector

transistor

PM-T65W-P

PNP open-collector

transistor

26.2

1.031

15.7

0.618

14.9 0.587

PM-L65

NPN open-collector

transistor

PM-L65-P

PNP open-collector

transistor

14.9 0.587

22.7

0.894

13.4

0.528

PM-Y65

NPN open-collector

transistor

PM-Y65-P

PNP open-collector

transistor

13.5 0.531

22.4

0.882

13.4

0.528

PM-F65

NPN open-collector

transistor

PM-F65-P

PNP open-collector

transistor

13 0.512

13.4

0.528

22.4

0.882

PM-F65W

NPN open-collector

transistor

PM-F65W-P

PNP open-collector

transistor

22.4

0.882

13.5 0.531

13.4

0.528

PM-R65

NPN open-collector

transistor

PM-R65-P

PNP open-collector

transistor

13 0.512

22.4

0.882

13.4

0.528

PM-R65W

NPN open-collector

transistor

PM-R65W-P

PNP open-collector

transistor

Note: “

W” in the model No. indicates that the product is mounting-compatible with our conventional models [PM-T53(B) / PM-□64(P)].

Compact / Connector built-in type

PM-65 SERIES

Cable type

NPN output

PNP output

Connector attached cable

1 m 3.281 ft, 2 m 6.562 ft,

3 m 9.843 ft, 5 m 16.404 ft

Connector attached bending-resistant cable

1 m 3.281 ft, 2 m 6.562 ft,

3 m 9.843 ft, 5 m 16.404 ft

Connector attached cable

1 m 3.281 ft, 2 m 6.562 ft,

3 m 9.843 ft, 5 m 16.404 ft

Connector attached bending-resistant cable

1 m 3.281 ft, 2 m 6.562 ft,

3 m 9.843 ft, 5 m 16.404 ft

Built-in connector

PM-K65

PM-T65

PM-T65W

PM-L65

PM-Y65

PM-F65

PM-F65W

PM-R65

PM-R65W

Easy mounting with

M2 / M3 screws!

Compact size!

Easy connection with a single touch

using commercially-available connectors
