Tooling

CT-1700

CT-720

CT-930, CT-930CH,

CT-920, CT-920CH,

CT-2920, CT-940CH

CT-980, CT-980CH,

CT-2950, CT-2980

CT-2001

PANDUIT

Part Number

PANDUIT Die Part Number

Die Index Number

(Number of Crimps)

S8-10R-Q

P21

(2)

CD-720-1

P21

(1)

CD-920-8

P21

(1)

—

CD-2001-8

P21

(1)

S8-14R-Q

S8-56R-Q

S8-38R-Q

S6-10R-E

P24

(2)

CD-720-1

P24

(1)

CD-920-6

P24

(1)

—

CD-2001-6

P24

(1)

S6-14R-E

S6-56R-E

S6-38R-E

S4-10R-E

P29

(2)

CD-720-1

P29

(1)

CD-920-4

P28

(1)

STD

(1)

CD-2001-4

P29

(1)

S4-14R-E

S4-56R-E

S4-38R-E

S2-10R-X

P37

(3)

CD-720-2

P37

(1)

CD-920-1

P37

(1)

STD

(1)

CD-2001-1

P37

(1)

S2-14R-X

S2-56R-X

S2-38R-X

S2-12R-X

S1/0-14R-X

—

CD-720-2

P42

(1)

CD-920-1/0

P42

(1)

STD

(1)

CD-2001-1/0

P42

(1)

S1/0-56R-X

S1/0-38R-X

S1/0-12R-X

S2/0-14R-X

—

CD-720-2

P45

(2)

CD-920-2/0

P45

(1)

STD

(1)

CD-2001-2/0

P45

(2)

S2/0-56R-X

S2/0-38R-X

S2/0-76R-X

S2/0-12R-X

S3/0-14R-5

—

CD-720-2

P50

(2)

CD-920-3/0

P50

(1)

STD

(1)

CD-2001-3/0

P50

(2)

S3/0-56R-5

S3/0-38R-5

S3/0-76R-5

S3/0-12R-5

S4/0-38R-5

—

CD-720-3

P54

(2)

CD-920-4/0

P54

(1)

STD

(1)

CD-2001-4/0

P54

(2)

S4/0-76R-5

S4/012R-5

S250-56R-5

—

CD-720-3

P62

(2)

CD-920-250

P62

(1)

STD

(1)

CD-2001-250

P62

(2)

S250-38R-5

S250-76R-5

S250-12R-5

Tooling Selection Guide for

PANDUIT Tubular Ring Terminals
