Pro LED Panel Indicator

Newark.com/multicomp-pro

Farnell.com/multicomp-pro

sg.element14.com/b/multicomp-pro

Features

• Best in class Ilumination

• SMD LED cluster technology

• Inbuilt low voltage glow protection

• Power consumption less than 1W

• IP65, IP20

• Witstand 2KV surge & passes 2.5KV HV test for 60 seconds

Specification

Product

: Pro LED Indicator

Rated Voltage

: 12V AC/DC, 24V AC/DC, 30V AC/DC, 48V AC/VDC, 64 V AC/DC,

110V AC,110V DC, 240 V AC, 220V DC, 415V AC

Operating Voltage

: -20% to +10% of rated voltage

Type of LED

: SMD LED’s

Available Colours

: Red / Green / Blue / Yellow / Amber / White

Life / Warranty

: 0.5 Million burning hours/36 Months(At standard operating conditions)

Operating Frequency

: 50/60 Hz

Operating Temperature

: -25°C to 65°C

Storage Temperature

: -30°C to 70°C

Wire Termination Capacity

: 0.5 mm2, 1.5 mm2 - 2.5 mm2

LED Arrangement

: Cluster Type

Terminal Torque

: 1 Nm

Low Voltage Glow Protection

: Available

Surge Test

: 2KV

Hv Test for 60 sec.

: 2.5KV

Degree of Protection

: Above Panel: IP65/ For Terminals: IP20

International Approvals

: CE
