RATINGS:

A2D-R

Volts: 250VAC/DC

Amps: 1/10 to 600A (AC),

15 to 600A (DC)

IR: 200kA I.R. AC,

100kA I.R. DC

A6D-R

Volts: 600VAC/DC

Amps: 1/10 to 600A

IR: 200kA I.R. AC, 100kA I.R.

DC (Self-certified for 300kA

I.R., UL witnessed.)

APPLIC ATIONS:

•

Motors

•

Safety switches

•

Transformers

•

Branch circuit protection

•

Disconnects

•

Control panels

•

All general-purpose

circuits

Note: See motor fuse applications

tables on page P7

APPRO VALS:

•

UL listed to standard

248-12 File E2137

•

DC listed to UL

standard 248

•

CSA certified to standard

C22.2 No. 248.12

The Amp-Trap 2000® A2D-R and A6D-R fuses provide IEC Type 2 No

Damage protection to main, feeder, and branch circuits for all types

of loads. With time-delay characteristics for handling harmless inrush

currents, current-limiting ability and a wide range of ratings (from 1 to

600 Amperes), A2D-R and A6D-R fuses give excellent protection for all

your applications.

FEATURES/BENEFIT S:

•

Non-indicating or solid state SmartSpot® visual blown fuse indicator

•

Time-delay for motor starting and transformer inrush currents

without nuisance opening

•

600VAC & 600VDC dual rated

•

300kA interrupting rating - self-certified, UL witnessed tests

•

Extremely current-limiting for low peak let-thru current

•

Recommended for Arc Flash energy reduction

•

Easy 2-to-1 selectivity for prevention of nuisance shut downs and

“black outs”

•

Rejection-style design prevents replacement errors (when used with

recommended fuse blocks)

•

High-visibility orange label gives instant brand recognition

•

Reduced inventory by taking the place of class RK5, K, and H fuses

•

Metal-embossed date and catalog number for easier traceability and

lasting identification

•

Fiberglass body provides dimensional stability in harsh industrial

settings

A2D-R & A6D-R

Time Delay/Class RK1

UL/CSA LISTED POWER FUSES

UPGRADE YESTERDAY’S CIRCUITS TO

TODAY’S TYPE 2 PROTECTION
