DS039-10

Sept ‘05

©2005 REG No 277 4001, ENGLAND.

Page 3

Antenna

¼ Wave Whip Antenna Dimensions (mm)

M4

4BA

BNC

BNC 90°

Length

Dia

Length

Dia

Dia

Length

Dia

Length

315MHz

*

*

231

18

13

250

433MHz

162.5

13

160.5

17

13

172

*

*

458MHz

-

-

-

16

-

164

868MHz

97

13

-

17.5

-

81

916MHz

-

-

83

-

13

-

Helical / Compressed Helical / Gain Antenna Dimensions (mm)

Helical M4

Helical 4BA

Helical BNC

Comp. Helical

M4

Gain

Length

Dia

Length

Dia

Length

Dia

Length

Dia

Length

Dia

173MHz

-

-

*

*

-

-

-

-

*

*

315MHz

-

-

72

13

105

17

-

-

*

*

433MHz

55

14

55.5

13

84

17

35

14

490

14

458MHz

-

-

-

-

81

17

-

-

-

-

868MHz

-

-

-

-

-

-

-

-

-

-

916MHz

-

-

83

13

*

*

-

-

-

-

Puk / Dipole Antenna Dimensions (mm)

Puk

Dipole

Height

Dia

Cable Length

Length

Width

Height

Cable Length

433MHz

52

47

500

900/1800 MHz

112

60

10

175

GPS Antenna Dimensions (mm)

GPS - SMA / HFL

GPS - MMCX

Height

Dia

Cable Length

Height

Dia

Cable Length

1575 MHz

10

56

5000

14.5

49

5000
