Multi-layer Chip Diplexer

ADID-R-0005

1.0 x 0.5 x 0.38 mm

RoHS Compliant

5101 Hidden Creek Ln Spicewood TX 78669

Phone: 512-371-6159 | Fax: 512-351-8858

REVISED: 02-19-24

For terms and conditions of sales, please visit:

www.abracon.com

Request Samples

Check Inventory

Parameters

Specification

Units

Notes

Center Frequency

2400-2500

4900-5950

MHz

Insertion Loss (Max)

0.60

0.95

@25℃

Absolute Attenuation

23dB min. at 4800~6000 MHz

23 dB min. at 7200~7500 MHz

25 dB min. at 30~2400 MHz

27 dB min. at 2400~2500 MHz

23 dB min. at 2500~2690 MHz

20 dB min. at 9800~11900 MHz

Isolation (Min)

27 dB min. at 2400~2500 MHz

23 dB min. at 4900~5950 MHz

Return Loss (Min)

@25℃

Power Capacity

2.0

Parameters

Specifications

Filter Dimension

1.0 x 0.5 x 0.38 mm

Mounting Type

SMD Mount

Parameters

Specifications

Operating Temperature

-40ºC ~ +85ºC

Storage Temperature

-10ºC ~ +45ºC

Humidity

70% R.H.

RoHS Compliant

Yes

Electrical Specifications

Environmental Specifications

Mechanical Specifications
